断路器开关和传感器恒温器
Sensata 是全球飞机行业的断路器领先供应商,已经建立了质量,可靠性和性能的行业标准。 Sensata Technologies公司已经开创了几乎所有在当今飞机上使用的飞机断路器风格。 Sensata的全系列断路器提供了广泛的类型,功能和设计选项。
Sensata Technologies为所有航空航天,卫星,商业和军用飞机,医疗设备和暖通空调市场提供各种精密恒温器。我们的克里克森精密恒温器专为在恶劣环境中的温度保护或控制而设计。
Sensata 提供广泛的精密开关选择,非常适合坚固的应用。 Sensata Technologies还为航空航天和电子应用制造了一个密封的快速动作压力开关线,其中高可靠性和耐恶劣环境是必不可少的。
飞机断路器
Sensata 以前的德州仪器公司,已经开创了几乎每一种使用的断路器风格,以及下一代飞机的固态功率控制器技术。
热断路器
使用双金属快动盘作为感应和致动元件,Klixon热断路器具有无故障的过电流保护,适用于恶劣环境。他们广泛的产品线允许设计工程师灵活地选择最适合应用的断路器。请参阅Sensata部分,了解完整的目录细目和产品详细信息。
精密恒温器
利用双金属,快速作用的光盘作为热敏元件,克里克森精密恒温器具有极高的可靠性和长寿命。标准配置,探头样式包或定制包装可以满足大多数设计要求。
精密开关
Klixon密封微型和次微型快动开关是飞机,军事,航空航天和飞机发动机应用中非常苛刻和苛刻环境的理想选择。 Klixon的精密密封开关在广泛的应用中已经使用了40多年,可以在几乎所有商业和军用飞机以及世界各地的各种航天器和卫星上找到。
电机保护器
Sensata Klixon系列电机控制和保护器是行业的领导者。从飞机到家用电器,从照明保护到工业电机Sensata都有应用的产品。
eries | Description / Mil-Specification | Additional Info |
Aircraft Circuit Breakers | ||
APD | Arc Fault Protection Devices | |
2TC2 | Single Phase, Std. Circuit Breaker, 7/16 Bushing MS3320 | |
2TC27 | Single Phase, Std. Circuit Breaker, with 1-1/8" Long Pushbutton MS3320-_L | |
2TC63 | Single Phase, High Vibration Circuit Breaker MS3320-_V | |
3TC2 | Single Phase, Standard High Amp Circuit Breaker, 7/16" Bushing MS14105 | |
3TC14 | Single Phase, Standard High Amp Circuit Breaker, 15/32" Bushing | |
6TC2 | Three Phase, Standard Circuit Breaker, 7/16" Bushing MS14154 | |
6TC14 | Three Phase, Standard Circuit Breaker, 15/32" Bushing, LG Barrier | |
6TC37 | Three Phase, Standard Circuit Breaker, with Long Button MS14154-_L | |
6TC63 | Three Phase, High Vibration Circuit Breaker MS14154-_V | |
9TC2 | Three Phase, Standard High Amp Circuit Breaker, SM Barrier MS14153 | |
9TC14 | Three Phase, Standard High Amp Circuit Breaker, 15/32" Bushing SM Barrier | |
2TC49 | Dual Safety Circuit Breaker, 7/16" Bushing M5809/1 | |
3SB2 | Simulator Circuit Breaker | |
3SB4 | Simulator Circuit Breaker, with Auxiliary Contacts | |
5TC | Single Phase Ambient Compensated Circuit Breakers | |
20TC2 | Rocker Actuator Circuit Breaker, Raised Mounting Bracket | |
20TC4 | Rocker Actuator Circuit Breaker, Flush Mounting Bracket | |
6752-12 | Single Phase, High Short Circuit Capacity, "Red" C.B. | |
6752-13 | Single Phase, High Short Circuit Capacity, "Red" C.B., W/Aux Contacts | |
6752-100 | Single Phase, High Short Circuit Capacity MS25361 | |
6752-102 | Single Phase, High Short Circuit Capacity, High Vibration MS25361-_V | |
6752-305 | Three Phase, High Short Circuit Capacity, "Red" C.B. | |
3TC7 | Single Phase, Non-Ambient Compensated Circuit Breaker MS25244 | |
7270-1 | Miniature A/C Circuit Breaker, Toggle Actuator, 15/32" Bushing MS24509A | |
7270-7 | Miniature A/C Circuit Breaker, Toggle Actuator, Cover Plate Mounting MS24509B | |
7271-3 | Miniature A/C Circuit Breaker, Pushbutton C.B., Cover Plate Mounting MS24510B | |
7271-8 | Miniature A/C Circuit Breaker, Pushbutton C.B., 15/32" Bushing MS24510A | |
7274-2 | Low Amp, High Performance C.B., Short Case,7/16" Bushing MS26574 | |
7274-4 | Low Amp, High Performance C.B., Short Case,7/16" Bushing, w/Aux. Contacts MS26574A | |
7274-11 | Low Amp, High Performance C.B., Long Case,15/32" Bushing MS22073 | |
7274-69 | Low Amp, High Performance C.B.,High Vibration, Long Case,15/32" Bushing MS22073-_V | |
7277-1 | Low Amp, General Application C.B., w/Aux Contacts | |
7277-2 | Low Amp, General Application C.B. |
Series | Description / Mil-Specification | Additional Info |
Thermal Circuit Breaker | ||
C | CA, CM, CDA, CDM - 2 to 40 Amp, Commercial, Ignition Protected Thermal Breakers | |
7851, 7854 | 12.5 to 60 Amp Commercial, Sealed, Ignition Protected Thermal Breakers | |
F | 35 to 150 Amp Commercial, Surface Mounted Thermal Breakers | |
6766 | 35 to 150 Amp Commercial, Switchable Thermal Breakers | |
7855 | 175 to 200 Amp Commercial, Ignition Protected Thermal Breakers AA55571/03, AA55571/08 | |
PS | PSA, PSM, PSM-N - 2 to 35 Amp Precision Thermal Breakers AA55571/05, AA55571/06 | |
P | PDA, PDM - 2 to 40 Amp Precision, Sealed, Ignition Protected Thermal Breakers | |
9115 | Waterproof, 15 to 30 Amp Precision, Ignition Protected Thermal Breakers AA55571/01, AA55571/02 | |
PDLA, PDLM | 35 to 150 Amp Precision, Ignition Protected Thermal Breakers AA55571/04 , AA55571/07 |
Series | Description / Mil-Specification | Additional Info |
Precision Thermostats | ||
4344 | Welded Hermetic Seal Thermostats | |
6786 | Environmentally Sealed, Low Profile | |
7BT | Environmentally Sealed, High Capacity | |
Probes | Probe Packages, Immersion Type M24236/11, /25 | |
3BT-4BT | Tiny Stat Miniature M24236/13, /19 | |
5BT | SPDT, Welded, Hermetic Seal M24236/24 | |
M2 | Narrow Differential Welded, Hermetic Seal M24236/20 | |
M1/11041 | High Reliability, Hermetic Seal M24236/1 | |
4391 | Hermetically Sealed SPDT or SPST, Automatic or Manual Reset |
Series | Description / Mil-Specification | Additional Info |
Precision Switches | ||
AT | Snap Action Precision Position Switches | |
10AT, 11AT, 12AT | Hermetic Control Switch Packages | |
10AT Mil | Mil-Qualified Snap Action Precision Position Switches | |
KX | Precision Sine Switches | |
4HVS | High Performance Hermetic Interlock Switches | |
ESS | Environmentally Sealed Position Switches | |
6PS, 7PS | Hermetic Stainless Steel Pressure Switch | |
M8805 Mil-Spec Switch Qualifications | ||
Sensors | ||
2SE | Solid-State Air Flow Sensors |
Series | Description / Mil-Specification |
Motor Protectors | |
Motor Protectors Overview | |
8AM | AC on–winding motor protection up to 60 amps |
2AM, 3AM, 4AM | AC on–winding motor protection |
15AM | Motor protector and thermal cut–out |
2MM | Battery protector and thermal cut–out |
BJE | Non-Hermetic, Three phase motor protector 120 amps |
MJE | Non-Hermetic, Three phase motor protector 60 amps |
SJE | Non-Hermetic, Three phase motor protector 30 amps |
SKA | Non-Hermetic, Single motor protector 16 amps |
Phenolic | Phenolic motor protectors AC off–winding non–hermetic single–phase |
