IW-Microwave 射频微波电缆
2019-10-21 16:52:25

IW-微波产品极低损耗电缆组件经过优化，可在各自的频率范围内工作，从低频到67 GHz。根据要求，我们能够适应定制组装配置，并可以挤出各种护套材料。能力使我们能够生产具有额外柔韧性，延长弯曲寿命，低温和高温范围以及耐油和腐蚀性材料的组件。

IW-Microwave 0471, 1151, 1251, 1401, 1403, 1501, 1503, 1571, 1573, 1601, 1603, 1701, 1703, 1801, 1803, 2301, 2303, 2801, 2803, 4806, RF085, RF141, RF250.bmp

IW-Microwave 0471, 1151, 1251, 1401, 1403, 1501, 1503, 1571, 1573, 1601, 1603, 1701, 1703, 1801, 1803, 2301, 2303, 2801, 2803, 4806, RF085, RF141, RF250

IW-Microwave 0471, 1151, 1251, 1401, 1403, 1501, 1503, 1571, 1573, 1601, 1603, 1701, 1703, 1801, 1803, 2301, 2303, 2801, 2803, 4806, RF085, RF141, RF250.jpg

订货代码	截止频率 (GHz)	电缆外径 (mm)	弯曲半径 (mm)	电缆重量(kg/km)	电容 (pF/ft)	延时 (nS/ft)	传播速率 (%)
IW-Microwave 0471	110	1.45	1.59	6.99	29	1.44	71
IW-Microwave 1151	62	2.46	12.70	29.76	29	1.44	71
IW-Microwave 1251	70	2.46	6.35	29.76	27	1.44	75
IW-Microwave 1401	50	3.30	6.35	28.28	24	1.2	83
IW-Microwave 1403	50	4.85	12.70	71.43	24	1.2	83
IW-Microwave 1501	45	3.66	6.35	32.74	24	1.2	83
IW-Microwave 1503	45	4.88	6.35	77.38	24	1.2	83
IW-Microwave 1571	42	3.99	6.35	38.69	24	1.2	83
IW-Microwave 1573	42	5.31	6.35	41.67	24	1.2	83
IW-Microwave 1601	32	4.06	7.94	44.64	29	1.44	71
IW-Microwave 1603	32	5.82	9.53	89.29	29	1.44	71
IW-Microwave 1701	38.5	4.32	6.35	16.37	24	1.22	83
IW-Microwave 1703	38.5	6.10	12.70	138.40	24	1.22	83
IW-Microwave 1801	32	4.83	12.70	55.06	24	1.2	83
IW-Microwave 1803	32	6.60	12.70	119.05	24	1.2	83
IW-Microwave 2301	26.5	5.84	19.05	66.97	24	1.2	83
IW-Microwave 2303	26.5	7.37	9.53	150.30	24	1.2	83
IW-Microwave 2801	19.5	7.75	25.40	116.08	24	1.2	83
IW-Microwave 2803	19.5	9.65	25.40	223.22	24	1.2	83
IW-Microwave 4806	11.5	12.19	57.15	297.63	24	1.2	83
IW-Microwave RF085	60	2.16	3.18	11.61	29	1.4	71
IW-Microwave RF141	32	3.66	3.18	37.20	29	1.4	71
IW-Microwave RF250	18	5.84	9.53	92.27	24	1.22	71
