Products
|  |
| Part Number | F(MHz)(Min) | F(MHz)(Max) | Power (W) | Size(mm) |
|---|---|---|---|---|
JA00010030P40 | 1.5 | 30 | 10 | 90 x 80 x 20 |
JA00010030P44 | 1.5 | 30 | 25 | 90 x 80 x 22 |
JA00010030P51 | 1.5 | 30 | 125 | 179 x 108 x 46 |
JA00010030P57 | 1.5 | 30 | 500 | 259 x 213 x 65 |
JA00010030P61 | 1.5 | 30 | 1200 | 415 x 278 x 65 |
JA00200100P49 | 20 | 100 | 80 | 109 x 109 x 37 |
JA00200100P46 | 20 | 100 | 40 | 90 x 90 x 22 |
JA00200500P45 | 20 | 500 | 30 | 90 x 90 x 22 |
JA00200500P48 | 20 | 500 | 60 | 194 x 97 x 24 |
JA00200500P49 | 20 | 500 | 80 | 197 x 97 x 24 |
JA00200500P50 | 20 | 500 | 100 | 194 x 97 x 24 |
JA00201000P48 | 20 | 1000 | 65 | 155 x 124 x 27 |
JA01000500P46 | 100 | 500 | 40 | 90 x 90 x 22 |
JA01000500P51 | 100 | 500 | 150 | 150 x 145 x 34 |
JA03900450P46 | 390 | 450 | 40 | 90 x 90 x 22 |
JA03900450P53 | 390 | 450 | 200 | 150 x 145 x 34 |
JA04003000P47 | 400 | 3000 | 50 | 135 x 75 x 24 |
JA04001000P47 | 400 | 1000 | 50 | 137 x 75 x 24 |
JA05002000P50 | 500 | 2000 | 100 | 206 x 86 x 21.5 |
JA05003000P52 | 500 | 3000 | 160 | 300 x 156 x 28 |
JA06501000P47 | 650 | 1000 | 50 | 135 x 75 x 24 |
JA07002700P50 | 700 | 2700 | 100 | 206 x 86 x 21.5 |
JA07001000P50 | 700 | 1000 | 100 | 206 x 86 x 21.5 |
JA07002700P47 | 700 | 2700 | 50 | 139 x 125 x 25 |
JA08003800P47 | 800 | 3800 | 40 | - |
JA10002000P43 | 1000 | 2000 | 20 | 135 x 75 x 24 |
JA11001700P47 | 1100 | 1700 | 100 | 206 x 86 x 21.5 |
JA11001700P50 | 1100 | 1700 | 100 | 206 x 86 x 21.5 |
JA11001700P53 | 1100 | 1700 | 200 | 300 x 156 x 28 |
JA18002200P47 | 1800 | 2200 | 50 | 137 x 75 x 24 |
JA20003000P47 | 2000 | 3000 | 50 | 139 x 125 x 25 |
JA20006000P43 | 2000 | 6000 | 20 | 115 x 83 x 19.5 |
JA20006000P47 | 2000 | 6000 | 50 | 160 x 94 x 19.5 |
JA20006000P50 | 2000 | 6000 | 100 | 197 x 86 x 40 |
JA24002700P50 | 2400 | 2400 | 100 | 206 x 86 x 21.5 |
JA40008000P47 | 4000 | 8000 | 50 | 135 x 83 x 19.5 |
JA44006000P46 | 4400 | 6000 | 40 | 134 x 123 x 22.5 |
JA55006000P43 | 5500 | 6000 | 20 | 110 x 109 x 23 |
JA57005900P43 | 5700 | 5900 | 20 | 110 x 109 x 23 |
JA57005900P46 | 5700 | 5900 | 40 | 134 x 123 x 22.5 |
JA600018000P47 | 6000 | 18000 | 50 | 203 x 152 x 62 |
