我们的数据总线电缆也符合波音规格。数据总线电缆通常用于信号传输飞机电缆。
波音公司BMS 13~48挤出交联ETFE
BMS 13~48挤出交联ETFE
航天飞机电缆,电缆
BMS 13~48挤出交联ETFE应用:
在飞机的各个领域普遍使用
BMS 13~48挤出交联ETFE额定电压:
600伏
Part Number | Specifications | Nom. Insul. Thick. (in) |
BMS13-48T01 | AWG Range of 10 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T02 | AWG Range of 16 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T03 | AWG Range of 10 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T04 | AWG Range of 12 to 24 with 2 to 5 Conductors | 0.006 |
BMS13-48T05 | AWG Range of 16 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T06 | AWG Range of 16 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T07 | AWG Range of 16 to 24 with 2 to 5 Conductors | 0.006 |
BMS13-48T08 | AWG Range of 4/0 to 24 with 1 to 6 Conductors | 0.010 |
BMS13-48T09 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.010 |
BMS13-48T10 | AWG Range of 4/0 to 24 with 1 to 7 Conductors | 0.008 |
BMS13-48T11 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.008 |
BMS13-48T12 | AWG Range of 8 to 24 with 1 to 4 Conductors | 0.008 |
BMS13-48T13 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.008 |
BMS13-48T14 | AWG Range of 12 to 24 with 2 to 5 Conductors | 0.008 |
BMS13-48T15 | AWG Range of 12 to 24 with 1 to 4 Conductors | 0.010 |
BMS13-48T16 | AWG Range of 10 to 24 with 1 to 6 Conductors | 0.015 |
BMS13-48T17 | AWG Range of 12 to 24 with 2 to 5 Conductors | 0.015 |
BMS13-48T18 | AWG Range of 12 to 24 with 1 to 4 Conductors | 0.015 |
BMS13-48T19 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.015 |
BMS13-48T20 | AWG Range of 18 to 20 with 2 to 5 Conductors | 0.015 |
BMS13-48T21 | AWG Range of 18 to 20 with 1 to 4 Conductors | 0.015 |
BMS13-48T22 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.015 |
BMS13-48T23 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.010 |
BMS13-48T24 | AWG Range of 16 to 24 with 1 to 4 Conductors | 0.010 |
BMS13-48T25 | AWG Range of 12 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T26 | AWG Range of 16 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T27 | AWG Range of 12 to 24 with 1 to 4 Conductors | 0.008 |
BMS13-48T28 | AWG Range of 16 to 24 with 1 to 5 Conductors | 0.008 |
BMS13-48T29 | AWG Range of 16 to 24 with 1 to 5 Conductors | 0.006 |
BMS13-48T30 | AWG Range of 16 to 24 with 2 to 5 Conductors | 0.006 |
BMS13-48T31 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.008 |
BMS13-48T32 | AWG Range of 16 to 24 with 1 to 6 Conductors | 0.008 |
BMS13-48T33 | AWG Range of 18 to 24 with 2 to 5 Conductors | 0.015 |
BMS13-48T34 | AWG Range of 18 to 24 with 1 to 4 Conductors | 0.015 |
BMS13-48T35 | AWG Range of 12 to 24 with 1 to 6 Conductors | 0.008 |
BMS13-48T36 | AWG Range of 12 to 24 with 1 to 6 Conductors | 0.00 |
