For over fifty years Tensol ite has been providing leading-edge designs in wire and cable . This product guide is intended to provide a wel l focused presentation of our product l ine in regards to your mar ket and products. Although it is by no means complete in regards to Tensol ite’s capabi l ities, it should provide a thorough star ting point to aid you in your design consider ations. The fol lowing Table of Contents should provide you with a good idea of how to uti l ize this guide to it’s ful lest potential ; your end result being a wire or cable that you have specified to your own requirements and needs. Thank you in advance for considering Tensol ite for your cabl ing requirements and needs. Please feel free to contact your local Tensol ite representative or cal l our corpor ate office at the numbe.

 can be used in various constructions. It also has value when considered as a single conductor offering a 5% weight savings over the ST construction while maintaining the same mechanical properties. SLT is available in 150°C, 200ºC and 260ºC. T LR  Encompasses a metric family of wire and cable with a temperature rating of 260°C. TLR is a multi-purpose normal weight wire which exhibits exceptional performance characteristics within the range of the critical parameters in airframe applications. 200°C and 260°C. S T - N o r m a l We i g h t , M u l t i- p u r p o s e Encompasses a family of wire and cable in three temperature ratings: 150°C, 200°C, 260°C. ST is a multi-purpose normal weight wire which exhibits exceptional performance characteristics within the range of the critical parameters in airframe applications. This construction offers enhanced Hydrolysis Resistance and Cut-Through. T L S - T h i c k Wa l l , A b r a s i o n Re s i s t a n t An increased wall version which can be utilized in applications requiring superior mechanical capabilities such as abrasion resistance and dynamic cut-through. This insulation system may be used as a reduced size and weight replacement for MIL-W-22759/5 to /8. TLS is rated at 260°C. T L A - A l u m i n u m C o n d u c t o r An increased wall thickness version utilizing an aluminum conductor for power feeder applications. Improved mechanical performance including superior flexibility as compared to traditional polyimide insulated power feeder cables. TLA is rated at 175°C.
