100W USBC Charger

USBC High Power charging and Data. Can charge mobile phones, tablets and laptops up to 100W. Upstream power management capabilities. Built in over current and temperature protection. Light pipe charging indicator. Intelligent thermal management and power loading features.USB Data: USB 2.0 High Speed.

USB Data: USB 2.0

Input voltage: 28VDC +/10%

Power Output: 5VDC, 9VDC, 15VDC, 20VDC (Configurable USB PD power profiles) Up to 100W

Charging specification: USB BC 1.2; Apple charging; USB PD 3.0

Watts: USBC: 100W

Connector cycle rating: 30,000

DualUSB

USBC and USBA High Power charging and Data. Can charge mobile phones, tablets and laptops up to 60W. Upstream power management capabilities. Built in over current and temperature protection. Light pipe charging indicator.

USB Data: USB 2.0 High Speed

Input voltage:28VDC +/-10%

Power Output: USBC, 20VDC @ 3A, 15VDC @ 3A, 9VDC @ 3A, 5VDC @ 3A; USBA, 5VDC @ 2.1A

Charging specification: USB BC 1.2; Apple charging; USB PD 3.0

Watts: USB C: 60W; USB A: 10.5W; USB C and A: 60W (45W and 10.5W)

Connector cycle rating: 30,000

NFC

Smart card and NFC tag reader.

Small formfactor

Low power

13.56Mhz operating frequency

USB 2.0 interface

5V or 28V input voltage configurations
