m22759/18-22-9镀锡铜线供应,西安福川电子科技有限公司

m22759/18-22-9镀锡铜线供应
西安福川电子科技有限公司2020-02-02 17:53:50

m22759/18-22-9

西安福川电子科技公司是主营业务为国防电子、军民两用电子元器件及组件产品设计、生产和分销业务、公司有着雄厚的技术力量与设备支持并与国外知名公司品牌搭建了稳固合作平台。目前公司已为众多研究所、军工企业、机器配套单位提供从设计选型到安装调试等一条龙服务。

PART NUMBER	AWG	Conductor Stranding	Approx LBS/MFT	min O.D. (in)	Max O.D. (in)	Cond. Material	Min. Temp	Max. Temp	Voltage
订货代码	线规	导体绞合	约磅/MFT	最小外径	最大外径	导体材质	最小温度	最大温度	电压伏
m22759/18-26-0	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-1	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-2	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-3	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-4	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-5	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-6	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-7	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-8	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-26-9	26	19/38	1.52	0.03	0.034	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-0	26	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-1	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-2	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-3	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-4	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-5	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-6	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-7	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-8	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-24-9	24	19/36	2.12	0.034	0.038	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-0	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-1	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-2	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-3	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-4	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-5	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-6	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-7	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-8	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-22-9	22	19/34	3.16	0.041	0.045	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-0	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-1	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-2	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-3	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-4	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-5	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-6	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-7	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-8	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-20-9	20	19/32	4.76	0.049	0.053	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-0	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-1	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-2	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-3	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-4	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-5	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-6	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-7	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-8	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-18-9	18	19/30	7.1	0.059	0.063	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-0	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-1	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-2	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-3	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-4	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-5	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-6	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-7	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-8	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-16-9	16	19/29	9.14	0.068	0.072	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-0	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-1	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-2	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-3	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-4	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-5	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-6	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-7	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-8	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-14-9	14	19/27	14.1	0.083	0.087	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-0	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-1	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-2	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-3	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-4	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-5	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-6	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-7	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-8	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-12-9	12	37/28	21.6	0.104	0.11	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-0	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-1	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-2	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-3	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-4	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-5	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-6	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-7	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-8	10	37/26	34.1	0.131	0.137	Stranded tin plated copper	-55°C	150°C	600
m22759/18-10-9	10	37/26	34.1	0.131	0.137	Stranded tin p

电话：029-88256270 传真：029-88257182 网址：www.aiboco.com 邮箱：sales@aiboco.com
