MIL-W-22759/44 (M22759/44) | SAE AS22759/44

Mil-Spec #         AWG    Stranding  Min O.D. (in)     MaxO.D. (in)    Nom.Lbs/Mft

M22759/44-28-* 28         7/36      0.025       0.029                   0.91

M22759/44-26-* 26         19/38    0.03         0.034                   1.4

M22759/44-24-* 24         19/36    0.035       0.039                    2

M22759/44-22-* 22         19/34    0.041       0.045                  2.8

M22759/44-20-* 20         19/32    0.048       0.052                  4.3

M22759/44-18-* 18         19/30    0.058       0.062                  6.5

M22759/44-16-* 16         19/29    0.066       0.07                     8.3

M22759/44-14-* 14         19/27    0.082       0.088                   13

M22759/44-12-* 12          37/28   0.1          0.106                    19.7

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.

0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White

Example: Size 20, white - M22759/11-20-9; white with orange stripe -

M22759/11-20-93.
