MIL-W-22759/87 (M22759/87) | SAE AS22759/87

Finished Wire

Mil-Spec#               AWG   Stranding   Min O.D. (in)   MaxO.D. (in)  Approx LBS/MFT

M22759/87-26-*       26      19/38          0.033          0.037             1.6

M22759/87-24-*       24      19/36          0.037          0.041             2.2

M22759/87-22-*       22      19/34          0.043          0.047             3.1

M22759/87-20-*       20      19/32          0.051          0.055             4.7

M22759/87-18-*       18      19/30          0.064          0.068             7.4

M22759/87-16-*       16      19/29          0.068          0.073             8.8

M22759/87-14-*       14      19/27          0.081          0.086            13.2

M22759/87-12-*       12      37/28          0.100          0.105            20.2

M22759/87-10-*       10      37/26          0.122          0.127            32.2

M22759/87-8-*         8      133/29          0.180          0.188            58.0

M22759/87-6-*         6      133/27          0.219          0.229            90.0

M22759/87-4-*         4      133/25           0.276         0.288           143.0

M22759/87-2-*         2      665/30          0.344          0.364           221.0

M22759/87-1-*         1      817/30          0.388          0.408           288.0

M22759/87-01-*     1/0    1045/30          0.420          0.450          339.0

M22759/87-02-*     2/0    1330/30          0.475          0.505          424.0

M22759/87-03-*     3/0    1665/30          0.530          0.560          531.0

M22759/87-04-*     4/0     2109/30         0.590           0.630         668.0

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.

0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White

Example: Size 20, white - M22759/87-20-9; white with orange stripe -

M22759/87-20-93.
