m22759/30
军用规格线
m22759/30规范：
SAE as22759
Mil-DTL-22759
600V, 200°C
描述：m22759/30
导体：银涂层高强度铜合金
绝缘：挤压聚四氟乙烯
外套：聚酰亚胺涂层
指标：m22759/30
额定电压600伏供电
额定温度：200
应用：普通m22759/30
m22759/30线是适合使用在飞机引擎和在其他耐磨损的军事和民事应用。
PART NUMBER AWG Conductor Stranding Approx LBS/MFT min O.D. (in) Max O.D. (in) Cond. Material Max. Temp Voltage
M22759/30-28-0 28 7/36 1.35 0.032 0.036 Nickel coated copper 200°C 600
M22759/30-28-1 28 7/36 1.35 0.032 0.036 Nickel coated copper 200°C 600
M22759/30-28-2 28 7/36 1.35 0.032 0.036 Nickel coated copper 200°C 600
M22759/30-28-3 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-28-4 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-28-5 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-28-6 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-28-7 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-28-8 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-28-9 28 7/36 1.35 0.032 0.036 Silver coated high strength copper alloy 200°C 600
M22759/30-26-0 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-1 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-2 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-3 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-4 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-5 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-6 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-7 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-8 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-26-9 26 19/38 1.93 0.037 0.041 Silver coated high strength copper alloy 200°C 600
M22759/30-24-0 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-1 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-2 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-3 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-4 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-5 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-6 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-7 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-8 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
M22759/30-24-9 24 19/36 2.63 0.042 0.046 Silver coated high strength copper alloy 200°C 600
m22759/30-22-0 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-1 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-2 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-3 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-4 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-5 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-6 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-7 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-8 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-22-9 22 19/34 3.68 0.048 0.052 Silver coated high strength copper alloy 200°C 600
m22759/30-20-0 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-1 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-2 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-3 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-4 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-5 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-6 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-7 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-8 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
m22759/30-20-9 20 19/32 5.45 0.057 0.061 Silver coated high strength copper alloy 200°C 600
