mil-w-22759 | SAE as22759/28
mil-w-22759/28
SAE as22729
军用规格钢丝
m22759 / 28线建设：
导体：镀银铜
绝缘：挤压聚四氟乙烯
外套：聚酰亚胺涂层
m22759 / 28线额定值：
额定电压：600伏
温度等级：260°
PART NUMBER AWG Conductor Stranding Approx LBS/MFT min O.D. (in) Max O.D. (in) Cond. Material Max. Temp Voltage
M22759/28-28-0 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-1 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-2 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-3 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-4 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-5 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-6 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-7 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-8 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-28-9 28 7/36 1.35 0.032 0.036 Silver coated copper 260°C 600
M22759/28-26-0 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-1 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-2 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-3 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-4 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-5 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-6 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-7 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-8 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-26-9 26 19/38 1.92 0.037 0.041 Silver coated copper 260°C 600
M22759/28-24-0 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-1 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-2 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-3 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-4 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-5 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-6 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-7 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-8 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
M22759/28-24-9 24 19/36 2.61 0.042 0.046 Silver coated copper 260°C 600
m22759/28-22-0 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-1 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-2 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-3 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-4 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-5 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-6 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-7 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-8 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-22-9 22 19/34 3.66 0.048 0.052 Silver coated copper 260°C 600
m22759/28-20-0 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-1 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-2 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-3 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-4 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-5 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-6 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-7 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-8 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
m22759/28-20-9 20 19/32 5.42 0.057 0.061 Silver coated copper 260°C 600
M22759/28-18-0 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-1 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-2 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-3 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-4 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-5 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-6 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-7 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-8 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-18-9 18 19/30 8.05 0.067 0.071 Silver coated copper 260°C 600
M22759/28-16-0 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-1 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-2 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-3 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-4 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-5 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-6 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-7 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-8 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-16-9 16 19/29 9.88 0.073 0.079 Silver coated copper 260°C 600
M22759/28-14-0 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-1 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-2 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-3 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-4 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-5 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-6 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-7 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-8 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-14-9 14 19/27 14.9 0.088 0.094 Silver coated copper 260°C 600
M22759/28-12-0 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-1 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-2 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-3 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-4 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-5 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-6 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-7 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-8 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-12-9 12 19/25 23 0.108 0.114 Silver coated copper 260°C 600
M22759/28-10-0 10 37/26 35.2 0.137 0.143 Silver coated copper 260°C 600
M22759/28-10-1 10 37/26 35.2 0.137 0.143 Silver coated copper 260°C 600
M22759/28-10-2 10 37/26 35.2 0.137 0.143 Silver coated copper 260°C 600
