mil-w-22759| SAE as22759/13/
mil-w-22759/13
SAE as22729
军用规格线缆
m22759/13电缆构成：
导体：镀锡铜
绝缘：挤出FEP
护套：聚偏氟乙烯
m22759/13电缆的额定值：
额定电压：600伏
M22759/13额定工作温度:135°C
PART NUMBER AWG Conductor Stranding Approx LBS/MFT min O.D. (in) Max O.D. (in) Cond. Material Max. Temp Voltage
M22759/12-28-0 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-1 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-2 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-3 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-4 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-5 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-6 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-7 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-8 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-28-9 28 7/36 2 0.031 0.035 Nickel Plated Copper 260°C 600
M22759/12-26-0 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-1 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-2 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-3 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-4 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-5 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-6 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-7 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-8 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-26-9 26 19/38 2 0.036 0.04 Nickel Plated Copper 260°C 600
M22759/12-24-0 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-1 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-2 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-3 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-4 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-5 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-6 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-7 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-8 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-24-9 24 19/36 3 0.041 0.045 Nickel Plated Copper 260°C 600
M22759/12-22-0 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-1 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-2 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-3 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-4 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-5 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-6 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-7 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-8 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-22-9 22 19/34 4 0.047 0.051 Nickel Plated Copper 260°C 600
M22759/12-20-0 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-1 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-2 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-3 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-4 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-5 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-6 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-7 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-8 20 19/32 6 0.056 0.06 Nickel Plated Copper 260°C 600
M22759/12-20-9 20 19/32 6 0.056 0.06 Nickel Plated Copper
