PN    AWG    ConductorStranding    Approx LBS/MFT    Min O.D. (in)    Max O.D. (in)    Mil-Spec    SAE Spec    Cond. Material    Insul. Material    Jacket Material    Max. Temp    Shield    Shield Material    Voltage

M22759/2-22-0    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-1    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-2    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-3    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-4    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-5    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-6    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-7    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-8    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-22-9    22    19/34    7.5    0.08    0.088    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-0    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-1    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-2    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-3    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-4    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-5    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-6    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-7    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-8    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-20-9    20    19/32    9.5    0.09    0.098    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-0    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-1    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-2    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-3    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-4    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-5    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-6    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-7    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-8    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-18-9    18    19/30    13    0.1    0.11    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-0    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-1    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-2    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-3    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-4    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-5    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-6    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-7    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-8    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-16-9    16    19/29    16.5    0.115    0.125    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600

M22759/2-14-0    14    19/27    23    0.133    0.143    M22759/2    AS22759/2    Nickel-Plated Copper    PTFE    PTFE    260°C    Impregnated Glass Braid    Polytetrafluoroethylene (PTFE) Coated Fiberglass    600
