Tri-Start option CLUTCH-LOK为MIL-DTL-38999系列III连接器提供了不锈钢/K级防火墙的所有优点，加上独特的离合器设计，可在振动下自动收紧。LeapinLar字幕高阶差动转矩不能回到下一个棘轮齿上与所有现有MIL-DTL-38999完全兼容系列III连接器，在交通不便、交通不便的地区提供优势，配合扭矩难以施加，整个联轴器无法通过检查验证。
HD38999系列连接器的接触密度比最高密度的Mil Spec 38999连接器高30%
它的大小。该系列连接器设计用于使用mil指定的38999组件，但触点和插入件布置除外。利用现有的MIL合格的39029尺寸23触点和38999个插入材料，这些连接器本质上是标准连接器38999的替代物的掉落。
H 38999高密度
38999个这种连接器的设计有两种不同的方式让用户受益。对于那些需要增加他们的应用，HD38999系列允许他们这样做，而不增加他们的连接器的大小。对于希望减小系统总体大小的用户，可以使用较小的外壳大小，而不必减少联系人的数量。安费诺已使该系列连接器符合MIL-DTL-38999的要求
SERVICE CLASS | ||||
Military | Finish | RoHS | Material | Material/ Description |
C | Anodic Coating | ■ | Aluminum | 200°C, 500 hour salt spray |
F | Electroless Nickel | ■ | Aluminum | 200°C, EMI shielding –65dB @ 10GHz, 48 hour salt spray |
G | Electroless Nickel | ■ | Aluminum | 200°C, Space grade, 48 hour salt spray |
J | Olive Drab Cadmium | Composite | 175°C, 2000 hours dynamic salt spray, EMI Shielding –50 dB@10 GHz specification min. | |
K | Passivated Stainless Steel | ■ | Stainless Steel | 200°C, firewall capability, 500 hour salt spray resistance, EMI –45 dB @ 10 GHz specification min. |
L | Stainless Steel w/ Nickel Plate | ■ | Stainless Steel | Corrosion resistant steel, 200°C, 500 hour salt spray, , non firewall, EMI shielding –65dB @ 10GHz specification min. |
M | Electroless Nickel | ■ | Composite | 200°C, EMI shielding –65dB @ 10GHz, 2000 hours dynamic salt spray |
N | Stainless Steel w/ Nickel Plate | ■ | Stainless Steel | Hermetic connectors, corrosion resistant steel, 200°C |
S | Stainless Steel w/ Nickel Plate | ■ | Stainless Steel | Non-hermetic connectors, corrosion resistant steel, 200°, firewall capability, 500 hour salt spray, EMI shielding –65dB @ 10GHz specification min. |
T | Durmalon plated | ■ | Aluminum | Nickel-PTFE alternative to Cadmium, 175°C, 500 hour salt spray, EMI -50dB at 10GHz specification min. |
W | Olive Drab Cadmium | Aluminum | 175°C , 500 hour salt spray, EMI Shielding –50 dB@10 GHz specification min. | |
Y | Stainless Steel | ■ | Stainless Steel | Hermetic seal, 200°C passivated stainless steel |
Z | Zinc-Nickel Plated | ■ | Aluminum | Zinc-Nickel Alternative to Cadmium, +175°C, 500 hour salt spray, EMI Shielding –50 dB @ 10 GHz specification min. |
