Deutsch公司的 DL66R12-12PN-6116-LC 是一款 DL 系列, MIL-DTL-83723 III系列相等直型插头, 12 个触芯。这款快速连接 DL 系列连接器坚固耐用, 可用于高温应用。DL 系列连接器采用高质量触芯固定系统, 具有优秀的电气性能。设计可承受冲击, 暴露和振动。该产品可连接Souriau连接器, 所有MIL-DTL-83723 III, MIL-DTL-26500卡口式连接器。
5键槽, 3点卡口式连接器, 可选键极化外壳, 或旋转嵌芯
高可靠性, 高密度连接器, 易于安装
工作温度范围: -65°C至+200°C
刚性塑料介质绝缘体, 硅基弹性体密封
500次插拔, 25°C时 5000Mohm绝缘电阻
未连接时, 盐雾暴露48小时。连接时, 盐雾暴露452小时。
防斜插, 可承受恶劣环境条件
铝合金主体材料, 非导电黑色阳极氧化处理
铜合金压接插针触芯, 镀金
25年以来，ITT Cannon始终致力于为全球客户提供高度可靠的同轴RF连接器。ITT Cannon RF系列可达500次插拔，工作温度范围为-65°C至+165°C，非常适合航空、工业、手持设备及交通运输市场。此款RF同轴连接器带有防潮接口，有3种连接选项。SMA插头具备环境密封性，可与所有SMA连接器互配，工作频率高达18GHz，采用螺纹连接。SMB连接器采用推入连接，工作频率高达4GHz。 SMC连接器采用螺纹连接，工作频率高达10GHz。
