德州仪器(Texas Instruments),简称Tl,是全球领先的半导体公司，为现实世界的信号处理提 供创新的数字信号处理(DSP)及模拟器件技术。在复杂算法和高性能、高集成应用专用处理器曰 益发展的推动下，数字信号处理（DSP)出现了爆炸性增长。德州仪器(TI)是DSP产品支持领域公认 的领导者。SMJ320系列的DSP芯片跨越九代产品，为计算密集型应用提供了经济高效的军用解决方案。
2011年4月TI收购美国国家半导体（NationalSemiconductor)后，模拟IC产业被带入了另一个新的里
程。NS公司将模拟技术和数字技术相结合，专注基于模拟技术的半导体产品，包括电源管理、图 像技术、显示驱动器、音频及运算放大器、接口产品以及数据转换解决方案等领域的独立元件和 子系统。
应用领域：航天航空、军工、数据处理、医疗设备、工业系统等
数字信号处理（DSP)系列产品
Part# | Description | Sub Family |
SMJ320C25 | Digital Signal Processors | TMS320C2X DSP |
SMJ320C30 | Digital Signal Processor | TMS320C3X DSP |
SMJ320C40 | Floating-Point DSP, Military | TMS320C4X DSP |
SMJ320C40KGDD | Floating-Point DSP Known Good Dies | TMS320C4X DSP |
SMJ320C6701 | Digital Signal Processors | C67x DSP |
SMJ320C6415 | Digital Signal Processors | C64x DSP |
TMS320C2801 | 32-Bit Digital Signal Controller with ROM | C28x Fixed-pointMCUS |
TMS320C6201 | C6000 Power Optimized DSP | C62x DSP |
TMS320C6416 | C6000 Power Optimized DSP | C64x DSP |
TMS320C6414 | C6000 Power Optimized DSP | C64x DSP |
TMS320C6678 | Multicore Fixed and Floating-Point DSP | C667x DSP |
TMS320C6671 | Fixed and Floating-Point DSP | C667x DSP |
TMS320C6654 | Fixed and Floating-Point DSP | C62x DSP |
TMS320C6657 | Fixed and Floating-Point DSP | C62x DSP |
Part Number | Description | # Input Channels | Power Consumption (Typ)(mW) | Interface | Operating Temperature Range(C) | Estimated Package Size (WxL)(mm2) |
ADC12J4000 | 12-Bit, 4.0 GSPS RF sampling ADC with JESD204B interface | 1 | 2000 | JESD204B | -40 to 85 | 68VQFN: 10x10: 100 mm2 |
ADC12D1800RF | 12-Bit, 1.8/3.6 GSPS RF sampling ADC | 2 | 4400 | Parallel LVDS, Serial SP Interface | I -40 to 85 | 292BGA: 27 x 27: 729 mm2 |
ADC 12D 1800 | 12-Bit, Single 3.6 GSPS Ultra High-Speed ADC | 2 | 4180 | Parallel LVDS, Serial SP Interface | -40 to 85 | 292BGA: 27x27: 729 mm2 |
ADC12D1600RF | 12-Bit, 2.0/3.2 GSPS RF sampling ADC | 2 | 3880 | Parallel LVDS, Serial SP Interface | -40 to 85 | 292BGA: 27x27: 729 mm2 |
ADC12D1600 | 12-Bit, 2.0/3.2 GSPS Ultra High-Speed ADC | 2 | 3880 | Parallel LVDS, Serial SP Interface | -40 to 85 | 292BGA: 27 x 27: 729 mm2 |
ADC 12D 1000 | 12-Bit, 1.0/2.0 GSPS Ultra High-Speed ADC | 2 | 3380 | Parallel LVDS, Serial SP Interface | -40 to 85 | 292BGA: 27 x 27: 729 mm2 |
ADS5400 | 12-bit, 1000 MSPS ADC with analog input buffei | 1 | 2200 | Parallel LVDS, Serial SP Interface | -40 to 85 | 100HTQFP: 14x14: 256 mm2 |
ADC 10D1500 | Low Power, 10-Bit, Dual 1.5 GSPS or Single 3.0 GSPS ADC | 2 | 3140 | Parallel LVDS, Serial SP Interface | -40 to 85 | 292BGA: 27 x 27: 729 mm2 |
ADC083000 | 8-Bit, 3 GSPS, High Performance, Low Power A/D Converter | 1 | 1900 | Parallel LVDS, Serial SP] Interface | -40 to 85 | 128HLQFP: 20x20: 484 mm2 |
ADC08D500 | High Performance, Low Power, Dual 8-Bit, 500 MSPS A/D Converter | 2 | 1400 | Parallel LVDS, Serial SP] Interface | -40 to 85 | 128HLQFP: 20 X 20: 484 mm2 |
ADC12DJ3200 | 12-bit, dual 3.2-GSPS or single 6.4-GSPS | 2 | - | Parallel LVDS, Serial SP1 Interface | -40 to 85 | FCBGA-144 |
ADC12J2700 | 1-Channel Single ADC Folding/Interpolating 2.7Gsps 12-bit | 1 | 2100 | JESD204B | -40 to 85 | 68-Pin VQFN |
ADS54J60 | 2-Channel Dual ADC Pipelined lGsps 16-bit | 2 | 1200 | JESD204B | -40 to 85 | 72-Pin VQFN |
ADS54J69 | 2-Channel Dual ADC Pipelined 500Msps 16-bit | 2 | 2250 | JESD204B | -40 to 85 | 72-Pin VQFN |
ADS5403 | Low Power 12-bit 500MS PS Analog-to-Digita 1 Converter | 1 | 1040 | DDR LVDS | -40 to 85 | 196NFBGA: 12x12:144 mm2 |
ADS5474 | 14-bit, 400 MSPS Analog-to-Digital Converter with Buffered Input | 1 | 2500 | Parallel LVDS | -40 to 85 | 80HTQFP: 12 x 12: 196 mm2 |
ADS4449 | Quad-Channel, 14-bit, 250-MSPS Low-Power ADC | 4 | 1470 | DDRLVDS | -40 to 85 | 144NFBGA: 10 x 10:100 mm2 |
ADS4229 | 12-Bit 250MSPS Dual Low Power ADC | 2 | 470 | Parallel CMOS, Parallel LVDS | -40 to 85 | 64VQFN:9x9:81mm2 |
ADS4249 | 14-Bit 250MSPS Dual Low Power ADC | 2 | 470 | Parallel CMOS, Parallel LVDS | -40 to 85 | 64VQFN:9x9:81mm2 |
ADS5444 | 13 Bit, 250MSPS ADC | 1 | 2250 | Parallel LVDS | -40 to 85 | B0HTQFP: 12x 12: 196 nm2 |
ADS5440 | 13 Bit, 210MSPS Pipeline ADC | 1 | 2250 | Parallel LVDS | -40 to 85 | 丽 TQFP: 12x12: 196 nm2 |
ADS5547 j | 4-Bit 210 MSPS ADC With User-Selectable )DR LVDS or CMOS Parallel Outputs | 1 | 1230 | Parallel LVDS, Serial SPI Interface | -40 to 85 | J8VQFN:7x7:49 mm2 |
ADS5517 ] | 1-Bit, 200 MSPS ADC With DDR JVDS/CMOS Outputs | 1 | 1230 | Parallel CMOS, Serial SPI Interface | -40 to 85 | 【8VQFN:7x7:49 mm2 |
ADS5424 ; | V Mbit, 105MSPS High Performance Bipolar Analog-to-Digital Converter | 1 | 1900 | Parallel LVDS, Serial SPI Interface | -40 to 85 f r | '2HTQFP: 10 x 10: 144 nm2 |
ADS6424 ( I | )uad 12-bit 105MSPS ADC with serialized .VDS output | 4 | 1350 | Parallel LVDS, Serial SPI Interface | -40 to 85 | 4VQFN:9x9:81mm2 |
L ADS5282 v | xjw Power 8-Channel, 12-Bit, 65MSPS ADC /ith Serialized LVDS Interface | 8 | I 616 | Parallel LVDS, Serial SPI Interface | -40 to 85 6 | 4VQFN:9x9:81mm2 |
ADS5271 ^ | -Channel, 12-Bit, 40/50MSPS ADC with erialized LVDS Interface | 8 | 957 | Parallel LVDS | -40 to 85 8 n | 0HTQFP: 12x 12: 196 im2 |
