描述。
MSK5176系列电压稳压器可在+1.5V， +1.7V， +1.9V， +2.5V， +3.3V， +5.0V和+12.0V配置。由于使用了具有单片技术的超级PNP输出通晶体管，所有都拥有超低dropout规格。在这种配置中，7.5安培的压降为425mV，这提高了效率，降低了功耗。精度保证1%的最大输出电压公差。该系列还提供了TTLCMOS兼容的开/关使能功能。MSK5176系列封装在一个空间高效的5引脚功率SIP，有两种风格，三引线弯曲选项。
MS Kennedy与西安福川电子科技提供了各种各样的电压稳压器，用于许多不同的应用。虽然每个产品线都有自己的优点，但它们也有许多共同的优点。例如，我们所有的稳压器都是军用密封包装，并可能被筛选到军用或工业规格。此外，大多数调节器可与各种铅弯配置，便于集成到许多系统。除了铅弯配置，各种包装也可提供。
大多数软件包提供直接连接到散热器的隔离标签。从电气的角度来看，MS Kennedy稳压器提供低噪音，为您的灵敏模拟应用提供干净的输出。以及优秀的电气规格。我们的稳压器也具有特殊的热特性。低ec值允许MSK实现高输出电流，同时提供紧凑的封装配置。下面是各种电压调整线路的具体优点的详细说明。有关任何电压调节器的更多详细信息，请查阅MSK电压调节器选择指南或每一个单独的数据表除了我们的标准线性稳压器。MS Kennedy也有一个高效率降压开关稳压器的生产线。这些开关稳压器的优点包括低静态电流，用户可编程的电流限制和“软启动”，以及保持内部功耗低的高效率。
MSK 5030系列可在2.5V, 3.3V。5.0 v或7。页面ofoV版本，而MSK 5040系列预置电压为5.0V。3.3 v。2.5 v和1.9 v。所有的开关稳压器额定输出电流高达4安培。这些设备以三种不同的模式运行，这取决于输出负载的程度。在低负载水平，它们以间断电感电流的脉冲跳跃式模式工作。当负载增加到当前阈值的10%到30%之间时。该设备将切换到连续电感电流脉冲跳变模式。如果输出负载大于电流阈值的30%，则该设备将以提供连续电感电流的恒频PWM模式运行。
| Part No. | Documents | Function | Max +Iout Amps | Max -Iout Amps | Max +Vin Volts | Max -Vin Volts | Typ +Dropout Volts | Typ -Dropout Volts | +Vout Volts | -Vout Volts | Hermetic? Y/N | Package Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part No. | Documents | Function | Max +Iout Amps | Max -Iout Amps | Max +Vin Volts | Max -Vin Volts | Typ +Dropout Volts | Typ -Dropout Volts | +Vout Volts | -Vout Volts | Hermetic? Y/N | Package Style |
| MSK5000 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 3.3 | 5.2 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5001 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 5 | 5 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5002 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 5 | 5.2 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5003 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 12 | 5 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5004 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 12 | 12 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5005 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 15 | 15 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5006 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 15 | 5 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5007 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 5 | 12 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5008 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 5 | 15 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5009 | DUAL POSITIVE/NEGATIVE, LDO, FIXED OUTPUT | 3 | 3 | 30 | 30 | 1.3 | 0.8 | 10 | 10 | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5010-12.0 | POSITIVE, ULTRA LDO, FIXED OUTPUT | 10 | 0 | 36 | 0 | 0.45 | 0 | 12 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5010-3.3 | POSITIVE, ULTRA LDO, FIXED OUTPUT | 10 | 0 | 36 | 0 | 0.45 | 0 | 3.3 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5010-5.0 | POSITIVE, ULTRA LDO, FIXED OUTPUT | 10 | 0 | 36 | 0 | 0.45 | 0 | 5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5012 | POSITIVE, ULTRA LDO, ADJUSTABLE OUTPUT | 10 | 0 | 36 | 0 | 0.45 | 0 | ADJ | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5101-00 | POSITIVE, LDO, ADJUSTABLE OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | ADJ | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-1.5 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.5 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-1.7 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.7 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-1.8 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.8 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-1.9 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.9 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-12.0 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 12 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-2.5 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 2.5 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-3.3 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 3.3 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5102-5.0 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 5 | - | Y | 10 PIN POWER FLATPACK | |
| MSK5115-00 | POSITIVE, LDO, ADJUSTABLE OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | ADJ | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-1.5 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-1.7 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.7 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-1.9 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 1.9 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-12.0 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 12 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-2.5 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 2.5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-3.3 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 3.3 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5116-5.0 | POSITIVE, LDO, FIXED OUTPUT | 1.5 | 0 | 26 | 0 | 0.35 | 0 | 5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5130-00 | POSITIVE, LDO, ADJUSTABLE OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | ADJ | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5130-3.3 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 3.3 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-1.5 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 1.5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-1.7 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 1.7 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-1.8 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 1.8 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-1.9 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 1.9 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-12.0 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 12 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-2.5 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 2.5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-3.3 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 3.3 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5131-5.0 | POSITIVE, LDO, FIXED OUTPUT | 3 | 0 | 26 | 0 | 0.35 | 0 | 5 | - | Y | 5 PIN POWER TOP OR Z-TAB | |
| MSK5140-1.5 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 1 | 0 | 1.5 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5140-1.7 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.8 | 0 | 1.7 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5140-1.8 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.7 | 0 | 1.8 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5140-1.9 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.6 | 0 | 1.9 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5140-2.0 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.5 | 0 | 2 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5140-2.5 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.34 | 0 | 2.5 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5140-3.3 | POSITIVE, LDO, FIXED OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.34 | 0 | 3.3 | - | Y | 3 PIN POWER TOP OR NO TAB | |
| MSK5141 | POSITIVE, LDO, ADJUSTABLE OUTPUT, LOW NOISE | 1.5 | 0 | 20 | 0 | 0.34 | 0 | ADJ | - | Y | 10 PIN POWER FLATPACK |
