Wolfspeed GaN on SiC产品线
西安福川电子科技有限公司2021-04-28 00:12:37

Wolfspeed GaN on SiC产品线

Wolfspeed .png

Wolfspeed推动了射频技术的发展，这些技术已成为横跨商业和军用航空，空中交通管制，气象服务，飞机对卫星通信，太空探索等领域的无线通信和雷达系统的骨干。 Wolfspeed的创新，包括基于SiC的GaN研究与开发方面的突破，完全集成的设计支持以及定制组装，所有这些都有助于Wolfspeed不断为客户提供尺寸，重量和功率方面均具有显着优势的解决方案。作为您完整的RF系统设计合作伙伴，我们在SiC（封装和裸模）和LDMOS器件上提供广泛的GaN产品组合。

订货代码	Technology	Frequency (Min)	Frequency (Max)	峰值输出功率	Gain	效率	工作电压	Form	封装类型
CGH60008D-GP4	GaN on SiC	DC	6 GHz	8 W	>12 dB	65%	28V	Discrete Bare Die	裸片
CGH60015D-GP4	GaN on SiC	DC	6 GHz	15 W	>12 dB	65%	28V	Discrete Bare Die	裸片
CGH60030D-GP4	GaN on SiC	DC	6 GHz	30 W	>12 dB	65%	28V	Discrete Bare Die	裸片
CGH60060D-GP4	GaN on SiC	DC	6 GHz	60 W	>12 dB	65%	28V	Discrete Bare Die	裸片
CGH60120D-GP4	GaN on SiC	DC	6 GHz	120 W	>12 dB	65%	28V	Discrete Bare Die	裸片
CMPA0060002D	GaN on SiC	DC	6 GHz	2 W	17 dB	30%	28V	MMIC Bare Die	裸片
CMPA0060025D	GaN on SiC	DC	6 GHz	25 W	18 dB	33%	50V	MMIC Bare Die	裸片
CMPA2560025D	GaN on SiC	2.5 GHz	6 GHz	25 W	24 dB	31%	28V	MMIC Bare Die	裸片
CMPA601C025D	GaN on SiC	6 GHz	12 GHz	25 W	32 dB	32%	28V	MMIC Bare Die	裸片
CGH40006P	GaN on SiC	DC	6 GHz	6 W	>11 dB	65%	28V	封装分立晶体管	Pill
CGH40006S	GaN on SiC	DC	6 GHz	6 W	>11 dB	65%	28V	封装分立晶体管	Plastic
CGH40010F	GaN on SiC	DC	6 GHz	10 W	>14 dB	65%	28V	封装分立晶体管	Flange
CG2H40025F	GaN on SiC	DC	6 GHz	25 W	>15 dB	62%	28V	封装分立晶体管	Flange
CGH40035F	GaN on SiC	DC	6 GHz	35 W	>13 dB	60%	28V	封装分立晶体管	Flange
CGH40045F	GaN on SiC	DC	4 GHz	45 W	>12 dB	55%	28V	封装分立晶体管	Flange
CGH40090PP	GaN on SiC	DC	4 GHz	90 W	>14 dB	55%	28V	封装分立晶体管	Push-Pull
CGH40120F	GaN on SiC	DC	3 GHz	120 W	>15 dB	70%	28V	封装分立晶体管	Flange
CGH40120P	GaN on SiC	DC	3 GHz	120 W	>15 dB	70%	28V	封装分立晶体管	Pill
CGH40180PP	GaN on SiC	DC	3 GHz	180 W	>15 dB	70%	28V	封装分立晶体管	Push-Pull
CMPA0060002F	GaN on SiC	DC	6 GHz	2 W	17 dB	23%	28V	Packaged MMIC	Flange
CMPA0060025F	GaN on SiC	DC	6 GHz	25 W	17 dB	28%	50V	Packaged MMIC	Flange
CMPA2560025F	GaN on SiC	2.5 GHz	6 GHz	25 W	24 dB	31%	28V	Packaged MMIC	Flange
CMPA601C025F	GaN on SiC	6 GHz	12 GHz	25 W	33 dB	32%	28V	Packaged MMIC	Flange
CGHV1J006D-GP4	GaN on SiC	DC	18 GHz	6 W	17 dB	60%	40V	Discrete Bare Die	裸片
CGHV1J025D-GP4	GaN on SiC	DC	18 GHz	25 W	17 dB	60%	40V	Discrete Bare Die	裸片
CGHV1J070D-GP4	GaN on SiC	DC	18 GHz	70 W	17 dB	60%	40V	Discrete Bare Die	裸片
CGHV1F006S	GaN on SiC	DC	15 GHz	6 W	>7 dB	52%	40V	封装分立晶体管	表面贴装
CGHV1F025S	GaN on SiC	DC	15 GHz	25 W	11 dB	51%	40V	封装分立晶体管	表面贴装
CGHV40320D-GP4	GaN on SiC	DC	4 GHz	320 W	19 dB	65%	50V	Discrete Bare Die	裸片
CGHV60040D-GP4	GaN on SiC	DC	6 GHz	40 W	>7 dB	65%	50V	Discrete Bare Die	裸片
CGHV60075D5-GP4	GaN on SiC	DC	6 GHz	75 W	>7 dB	65%	50V	Discrete Bare Die	裸片
CGHV60170D-GP4	GaN on SiC	DC	6 GHz	170 W	>7 dB	65%	50V	Discrete Bare Die	裸片
CGHV27060MP	GaN on SiC	DC	2.7 GHz	60 W	16.5 dB	64%	50V	封装分立晶体管	Plastic
CGHV35060MP	GaN on SiC	2.7 GHz	3.8 GHz	60 W	14.5 dB	67%	50V	封装分立晶体管	Plastic
CGHV40030F	GaN on SiC	DC	6 GHz	30 W	16 dB	70%	50V	封装分立晶体管	Flange
CGHV40050F	GaN on SiC	DC	4 GHz	50 W	16 dB	53%	50V	封装分立晶体管	Flange
CGHV40100F	GaN on SiC	DC	3 GHz	100 W	17.5 dB	55%	50V	封装分立晶体管	Flange
CGH09120F	GaN on SiC	DC	2.5 GHz	120 W	21 dB	35%	28V	封装分立晶体管	Flange
CGH21120F	GaN on SiC	1.8 GHz	2.3 GHz	120 W	15 dB	35%	28V	封装分立晶体管	Flange
CGH21240F	GaN on SiC	1.8 GHz	2.3 GHz	240 W	15 dB	33%	28V	封装分立晶体管	Flange
CGH25120F	GaN on SiC	2.5 GHz	2.7 GHz	120 W	>7 dB	30%	28V	封装分立晶体管	Flange
CGH27015F	GaN on SiC	DC	6 GHz	15 W	14.5 dB	28%	28V	封装分立晶体管	Flange
CGH27030F	GaN on SiC	DC	6 GHz	30 W	15 dB	28%	28V	封装分立晶体管	Flange
CGH27030S	GaN on SiC	DC	6 GHz	30 W	18 dB	33%	28V	封装分立晶体管	表面贴装
CGH27060F	GaN on SiC	DC	4 GHz	60 W	14 dB	27%	28V	封装分立晶体管	Flange
CGH35015F	GaN on SiC	DC	6 GHz	15 W	12 dB		28V	封装分立晶体管	Flange
CGH35030F	GaN on SiC	DC	6 GHz	30 W	12 dB	25%	28V	封装分立晶体管	Flange
CGH35060F1	GaN on SiC	3.3 GHz	3.6 GHz	60 W	12 dB	25%	28V	封装分立晶体管	Flange
CGH55015F1	GaN on SiC	DC	6 GHz	15 W	>10.5 dB	25%	28V	封装分立晶体管	Flange
CGH55030F1	GaN on SiC	DC	6 GHz	30 W	10 dB	25%	28V	封装分立晶体管	Flange
CGHV27015S	GaN on SiC	DC	6 GHz	15 W	21 dB	32%	50V	封装分立晶体管	表面贴装
CGHV27030S	GaN on SiC	DC	6 GHz	30 W	21 dB	32%	50V	封装分立晶体管	表面贴装
CMPA2735075D	GaN on SiC	2.7 GHz	3.5 GHz	75 W	28 dB	61%	28V	MMIC Bare Die	裸片
CMPA801B025D	GaN on SiC	8 GHz	11 GHz	25 W	28 dB	45%	28V	MMIC Bare Die	裸片
CGH31240F	GaN on SiC	2.7 GHz	3.1 GHz	240 W	12 dB	60%	28V	封装分立晶体管	Flange
CGH35060F2	GaN on SiC	3.1 GHz	3.5 GHz	60 W	12 dB	60%	28V	封装分立晶体管	Flange
CGH35240F	GaN on SiC	3.1 GHz	3.5 GHz	240 W	11.6 dB	57%	28V	封装分立晶体管	Flange
CGH55015F2	GaN on SiC	DC	6 GHz	10 W	12 dB	60%	28V	封装分立晶体管	Flange
CGH55030F2	GaN on SiC	DC	6 GHz	25 W	12 dB	60%	28V	封装分立晶体管	Flange
CGHV14250F	GaN on SiC	DC	1.6 GHz	250 W	18 dB	77%	50V	封装分立晶体管	Flange
CGHV14500F	GaN on SiC	1.2 GHz	1.4 GHz	500 W	16 dB	68%	50V	封装分立晶体管	Flange
CGHV31500F	GaN on SiC	2.7 GHz	3.1 GHz	500 W	12.75 dB	60%	50V	封装分立晶体管	Flange
CGHV35150F	GaN on SiC	2.9 GHz	3.5 GHz	150 W	13.5 dB	50%	50V	封装分立晶体管	Flange
CGHV35400F	GaN on SiC	2.9 GHz	3.5 GHz	400 W	11 dB	60%	50V	封装分立晶体管	Flange
CGHV59350F	GaN on SiC	5.2 GHz	5.9 GHz	350 W	11 dB	55%	50V	封装分立晶体管	Flange
CGHV96100F2	GaN on SiC	7.9 GHz	9.6 GHz	100 W	10 dB	45%	40V	封装分立晶体管	Flange
CMPA801B025F	GaN on SiC	8 GHz	11 GHz	25 W	16 dB	36%	28V	Packaged MMIC	Flange
CMPA1D1E030D	GaN on SiC	13.75 GHz	14.5 GHz	30 W	26 dB	25%	40V	MMIC Bare Die	裸片
CGHV50200F	GaN on SiC	4.4 GHz	5 GHz	200 W	11.5 dB	33%	40V	封装分立晶体管	Flange
CGHV96050F1	GaN on SiC	7.9 GHz	8.4 GHz	50 W	>13 dB	33%	40V	封装分立晶体管	Flange
CMPA1D1E025F	GaN on SiC	13.5 GHz	14.5 GHz	25 W	26 dB	16%	40V	Packaged MMIC	Flange
CGHV96050F2	GaN on SiC	7.9 GHz	9.6 GHz	50 W	10 dB	55%	40V	封装分立晶体管	Flange
CG2H80030D-GP4	GaN on SiC	DC	8 GHz	30 W	16.5 dB	65%	28V	Discrete Bare Die	裸片
CGHV14800F	GaN on SiC	1.2 GHz	1.4 GHz	800 W	16 dB	65%	50V	封装分立晶体管	Flange
CGHV59070F	GaN on SiC	4.5 GHz	5.9 GHz	70 W	12 dB	50%	50V	封装分立晶体管	Flange
CMPA1C1D060D	GaN on SiC	12.7 GHz	13.25 GHz	65 W	26 dB	30%	40V	MMIC Bare Die	裸片
CMPA5585030F	GaN on SiC	5.5 GHz	8.5 GHz	30 W	25 dB	30%	28V	Packaged MMIC	Flange
CMPA2735015S	GaN on SiC	2.7 GHz	3.5 GHz	15 W	33 dB	50%	50V	Packaged MMIC	Plastic
CMPA2735015D	GaN on SiC	2.7 GHz	3.5 GHz	15 W	32 dB	45%	50V	MMIC Bare Die	裸片
CMPA2735030S	GaN on SiC	2.7 GHz	3.5 GHz	30 W	32 dB	45%	50V	Discrete Bare Die	裸片
CMPA2735030D	GaN on SiC	2.7 GHz	3.5 GHz	30 W	30 dB	45%	50V	Discrete Bare Die	裸片
CG2H40010F	GaN on SiC	DC	6 GHz	10 W	>16 dB	65%	28V	封装分立晶体管	Flange
CG2H40045F	GaN on SiC	DC	4 GHz	45 W	>14 dB	55%	28V	封装分立晶体管	Flange
CGH40025F	GaN on SiC	DC	6 GHz	25 W	>13 dB	62%	28V	封装分立晶体管	Flange
CGHV40200PP	GaN on SiC	DC	3 GHz	250 W	21 dB	75%	50V	封装分立晶体管	Push-Pull
CG2H80015D-GP4	GaN on SiC	DC	8 GHz	15 W	>12 dB	70%	28V	Discrete Bare Die	裸片
CG2H80060D-GP4	GaN on SiC	DC	8 GHz	60 W	>12 dB	70%	28V	Discrete Bare Die	裸片
CMPA5585030D	GaN on SiC	5.5 GHz	8.5 GHz	30 W	30 dB	44%	28V	MMIC Bare Die	裸片
CG2H30070F	GaN on SiC	0.5 GHz	3 GHz	80 W	15 dB	55%	28V	封装分立晶体管	Flange
CGHV40180P	GaN on SiC	DC	2 GHz	200 W	24 dB	70%	28V/50V	封装分立晶体管	Pill
GTVA104001FA-V1	GaN on SiC	0.96 GHz	1.215 GHz	400 W	19 dB	70%	50V	封装分立晶体管	Earless
GTVA123501FA-V1	GaN on SiC	1.2 GHz	1.4 GHz	350 W	18 dB	71%	50V	封装分立晶体管	Earless
GTVA101K42EV-V1	GaN on SiC	0.96 GHz	1.4 GHz	1400 W	17 dB	68%	50V	封装分立晶体管	Bolt Down
GTVA311801FA-V1	GaN on SiC	2.7 GHz	3.1 GHz	180 W	15 dB	70%	50V	封装分立晶体管	Earless
GTVA107001EFC-V1	GaN on SiC	0.96 GHz	1.215 GHz	700 W	20 dB	70%	50V	封装分立晶体管	Bolt Down
CGHV37400F	GaN on SiC	3.3 GHz	3.7 GHz	550 W	14 dB	55%	48V	封装分立晶体管	Flange
PTVA030121EA-V1	LDMOS	0.39 GHz	0.45 GHz	12 W	25 dB	69%	50V	封装分立晶体管	Bolt Down
PTVA035002EV-V1	LDMOS	0.39 GHz	0.45 GHz	450 W	18 dB	64%	50V	封装分立晶体管	Bolt Down
PTVA101K02EV-V1	LDMOS	1.03 GHz	1.09 GHz	900 W	18 dB	65%	50V	封装分立晶体管	Bolt Down
PTVA102001EA-V1	LDMOS	0.96 GHz	1.6 GHz	200 W	18.5 dB	60%	50V	封装分立晶体管	Bolt Down
PTVA104501EH-V1	LDMOS	0.96 GHz	1.215 GHz	450 W	17.5 dB	58%	50V	封装分立晶体管	Bolt Down
PTVA120251EA-V2	LDMOS	0.5 GHz	1.4 GHz	25 W	18 dB	54%	50V	封装分立晶体管	Bolt Down
PTVA120501EA-V1	LDMOS	1.2 GHz	1.4 GHz	50 W	17 dB	50%	50V	封装分立晶体管	Bolt Down
PTVA123501EC-V2	LDMOS	1.2 GHz	1.4 GHz	350 W	17 dB	55%	50V	封装分立晶体管	Bolt Down
PTVA123501FC-V1	LDMOS	1.2 GHz	1.4 GHz	350 W	17 dB	55%	50V	封装分立晶体管	Earless
PTVA127002EV-V1	LDMOS	1.2 GHz	1.4 GHz	700 W	16 dB	56%	50V	封装分立晶体管	表面贴装
PTVA047002EV-V1	LDMOS	0.47 GHz	0.806 GHz	700 W	17.5 dB	29%	50V	封装分立晶体管	Bolt Down
CMPA5259025F	GaN on SiC	5.2 GHz	5.9 GHz	37 W	32 dB	50%	28V	封装分立晶体管	Flange
CMPA5259050F	GaN on SiC	5.2 GHz	5.9 GHz	50 W	30 dB	54%	28V	Packaged MMIC	Flange
CMPA0527005F	GaN on SiC	1.2 GHz	1.4 GHz	5 W	20 dB	47%	50V	Packaged MMIC	Flange
CGHV35120F	GaN on SiC	3.1 GHz	3.5 GHz	120 W	>7 dB	62%	50V	封装分立晶体管	Flange
CMPA901A035F	GaN on SiC	9 GHz	10 GHz	40 W	34 dB	35%	28V	Packaged MMIC	Flange
CG2H40120F	GaN on SiC	DC	2.5 GHz	130 W	20 dB	70%	28V	封装分立晶体管	Flange
CMPA2060035F	GaN on SiC	2 GHz	6 GHz	35 W	27 dB	35%	28V	Packaged MMIC	Flange
CG2H80120D-GP4	GaN on SiC	DC	8 GHz	120 W	>12 dB	65%	28V	Discrete Bare Die	裸片
CG2H80045D-GP4	GaN on SiC	DC	8 GHz	45 W	15 dB	65%	28V	Discrete Bare Die	裸片
CG2H40035F	GaN on SiC	DC	6 GHz	35 W	14 dB	64%	28V	封装分立晶体管	Flange
CMPA2060035D	GaN on SiC	2 GHz	6 GHz	35 W	29 dB	42%	28V	MMIC Bare Die	裸片
CMPA2735075F1	GaN on SiC	2.7 GHz	3.5 GHz	75 W	29 dB	57%	28V	Packaged MMIC	Flange
CMPA801B030D	GaN on SiC	8 GHz	11 GHz	30 W	28 dB	42%	28V	MMIC Bare Die	裸片
CMPA801B030F	GaN on SiC	8 GHz	11 GHz	30 W	16 dB	36%	28V	Packaged MMIC	Flange
CMPA2738060F	GaN on SiC	2.7 GHz	3.8 GHz	80 W	34 dB	54%	50V	Packaged MMIC	Flange
CMPA0060025F1	GaN on SiC	DC	6 GHz	25 W	17 dB	28%	50V	Packaged MMIC	Flange
CMPA0060002F1	GaN on SiC	DC	6 GHz	2 W	18 dB	25%	28V	Packaged MMIC	Flange
CGHV1F006S-AMP1	GaN on SiC	5.85 GHz	7.2 GHz	6 W	>7 dB	NA	40V	开发板	表面贴装
CGHV1F006S-AMP3	GaN on SiC	8.5 GHz	9.6 GHz	6 W	>7 dB	NA	40V	开发板	表面贴装
CGH55015P2	GaN on SiC	DC	6 GHz	10 W	12 dB	60%	28V	封装分立晶体管	Pill
CGH55015F2-AMP	GaN on SiC	5.4 GHz	5.9 GHz	10 W	12 dB	NA	28V	开发板	Flange
CGH40010P	GaN on SiC	DC	6 GHz	10 W	>14 dB	65%	28V	封装分立晶体管	Pill
CGH40010F-AMP	GaN on SiC	3.5 GHz	3.9 GHz	10 W	>14 dB	NA	28V	开发板	Flange
CG2H40025P	GaN on SiC	DC	6 GHz	25 W	>15 dB	64%	28V	封装分立晶体管	Pill
CG2H40025F-AMP	GaN on SiC	3.4 GHz	3.8 GHz	25 W	>15 dB	NA	28V	开发板	Flange
CG2H30070F-AMP2	GaN on SiC	0.5 GHz	3 GHz	80 W	15 dB	NA	28V	开发板	Flange
CG2H40010F-AMP	GaN on SiC	3.5 GHz	3.9 GHz	10 W	>16 dB	NA	28V	开发板	Flange
CG2H40010P	GaN on SiC	DC	6 GHz	10 W	>16 dB	65%	28V	封装分立晶体管	Pill
CG2H40035F-AMP	GaN on SiC	DC	6 GHz	35 W	14 dB	NA	28V	开发板	Flange
CG2H40035P	GaN on SiC	DC	6 GHz	35 W	14 dB	64%	28V	封装分立晶体管	Pill
CGHV96100F2-AMP	GaN on SiC	7.9 GHz	9.6 GHz	100 W	10 dB	NA	40V	开发板	Flange
CGHV96050F2-AMP	GaN on SiC	8.4 GHz	9.6 GHz	50 W	10 dB	NA	40V	开发板	Flange
CGHV27030S-AMP1	GaN on SiC	2.5 GHz	2.7 GHz	30 W	21 dB	NA	50V	开发板	表面贴装
CGHV27030S-AMP2	GaN on SiC	2.5 GHz	2.7 GHz	30 W	21 dB	NA	28V	开发板	表面贴装
CGHV27030S-AMP3	GaN on SiC	1.8 GHz	2.2 GHz	30 W	21 dB	NA	28V	开发板	表面贴装
CGHV27030S-AMP4	GaN on SiC	1.8 GHz	2.2 GHz	30 W	21 dB	NA	50V	开发板	表面贴装
CGHV27030S-AMP5	GaN on SiC	1.2 GHz	1.4 GHz	30 W	21 dB	NA	50V	开发板	表面贴装
CG2H40045P	GaN on SiC	DC	4 GHz	45 W	>14 dB	55%	28V	封装分立晶体管	Pill
CG2H40045F-AMP	GaN on SiC	2.3 GHz	2.7 GHz	45 W	>14 dB	NA	28V	开发板	Flange
CG2H40120P	GaN on SiC	DC	2.5 GHz	130 W	20 dB	70%	28V	封装分立晶体管	Pill
CG2H40120F-AMP	GaN on SiC	1.2 GHz	1.4 GHz	130 W	20 dB	NA	28V	开发板	Flange
CGH21120F-AMP	GaN on SiC	1.8 GHz	2.1 GHz	120 W	15 dB	NA	28V	开发板	Flange
CGH21240F-AMP	GaN on SiC	1.8 GHz	2.1 GHz	240 W	15 dB	NA	28V	开发板	Flange
CGH27015P	GaN on SiC	DC	6 GHz	15 W	14.5 dB	28%	28V	封装分立晶体管	Pill
CGH27015F-AMP	GaN on SiC	2.3 GHz	2.7 GHz	15 W	14.5 dB	NA	28V	开发板	Flange
CGH27030P	GaN on SiC	DC	6 GHz	30 W	15 dB	28%	28V	封装分立晶体管	Pill
CGH27030F-AMP	GaN on SiC	DC	6 GHz	30 W	15 dB	NA	28V	开发板	Flange
CGH27030S-AMP1	GaN on SiC	1.8 GHz	2.2 GHz	30 W	18 dB	NA	28V	开发板	表面贴装
CGH40006P-AMP	GaN on SiC	2 GHz	6 GHz	6 W	>11 dB	NA	28V	开发板	Pill
CGH40006S-AMP1	GaN on SiC	DC	6 GHz	6 W	>11 dB	NA	28V	开发板	表面贴装
CGH40025P	GaN on SiC	DC	6 GHz	25 W	>13 dB	62%	28V	封装分立晶体管	Pill
CGH40025F-AMP	GaN on SiC	3.4 GHz	3.8 GHz	25 W	>13 dB	NA	28V	开发板	Flange
CGH40035F-AMP	GaN on SiC	3.3 GHz	3.7 GHz	35 W	>13 dB	NA	28V	开发板	Flange
CGH40045P	GaN on SiC	DC	4 GHz	45 W	>12 dB	55%	28V	封装分立晶体管	Pill
CGH40045F-AMP	GaN on SiC	2.3 GHz	2.7 GHz	45 W	>12 dB	NA	28V	开发板	Flange
CGH40090PP-AMP	GaN on SiC	0.5 GHz	2.5 GHz	90 W	>14 dB	NA	28V	开发板	Push-Pull
CGH40120F-AMP	GaN on SiC	1.2 GHz	1.4 GHz	120 W	>15 dB	NA	28V	开发板	Flange
CGH40180PP-AMP	GaN on SiC	1.1 GHz	1.3 GHz	180 W	>15 dB	NA	28V	开发板	Push-Pull
CGH55030P2	GaN on SiC	DC	6 GHz	25 W	12 dB	60%	28V	封装分立晶体管	Pill
CGH55030F2-AMP	GaN on SiC	5.4 GHz	5.9 GHz	25 W	12 dB	NA	28V	开发板	Flange
CGHV14250P	GaN on SiC	DC	1.6 GHz	250 W	18 dB	77%		封装分立晶体管	Pill
CGHV14250F-AMP	GaN on SiC	DC	1.6 GHz	250 W	18 dB	NA		开发板	Flange
CGHV14500P	GaN on SiC	1.2 GHz	1.4 GHz	500 W	16 dB	68%		封装分立晶体管	Pill
CGHV14500F-AMP	GaN on SiC	1.2 GHz	1.4 GHz	500 W	16 dB	NA		开发板	Flange
CGHV14800P	GaN on SiC	1.2 GHz	1.4 GHz	800 W	16 dB	65%		封装分立晶体管	Pill
CGHV14800F-AMP	GaN on SiC	1.2 GHz	1.4 GHz	800 W	16 dB	NA		开发板	Flange
CGHV1F025S-AMP1	GaN on SiC	8.9 GHz	9.6 GHz	25 W	11 dB	NA	40V	开发板	表面贴装
CGHV27060MP-AMP1	GaN on SiC	2.5 GHz	2.7 GHz	60 W	16.5 dB	NA	50V	开发板	Plastic
CGHV31500F-AMP	GaN on SiC	2.7 GHz	3.1 GHz	500 W	12.75 dB	NA		开发板	Flange
CGHV35150P	GaN on SiC	2.9 GHz	3.5 GHz	150 W	13.5 dB	50%		封装分立晶体管	Pill
CGHV35150F-AMP	GaN on SiC	2.9 GHz	3.5 GHz	150 W	13.5 dB	NA		开发板	Flange
CGHV35400F-AMP	GaN on SiC	2.9 GHz	3.5 GHz	400 W	11 dB	NA	50V	开发板	Flange
CGHV40030P	GaN on SiC	DC	6 GHz	30 W	16 dB	70%	50V	封装分立晶体管	Pill
CGHV40030F-AMP2	GaN on SiC	0.5 GHz	2.7 GHz	30 W	16 dB	NA	50V	开发板	Flange
CGHV40050P	GaN on SiC	DC	4 GHz	50 W	16 dB	53%	50V	封装分立晶体管	Pill
CGHV40050F-AMP	GaN on SiC	0.8 GHz	2 GHz	50 W	16 dB	NA	50V	开发板	Flange
CGHV40100P	GaN on SiC	DC	3 GHz	100 W	17.5 dB	55%	50V	封装分立晶体管	Pill
CGHV40100F-AMP	GaN on SiC	0.5 GHz	2.5 GHz	100 W	17.5 dB	NA	50V	开发板	Flange
CGHV40100P-AMP	GaN on SiC	0.5 GHz	2.5 GHz	100 W	17.5 dB	NA	50V	开发板	Pill
CGHV40180F	GaN on SiC	DC	2 GHz	200 W	24 dB	70%	28V/50V	封装分立晶体管	Flange
CGHV40180F-AMP3	GaN on SiC	0.96 GHz	1.25 GHz	200 W	24 dB	NA	28V/50V	开发板	Flange
CGHV40200PP-AMP	GaN on SiC	1.7 GHz	1.9 GHz	250 W	21 dB	NA	50V	开发板	Push-Pull
CGHV50200F-AMP	GaN on SiC	4.4 GHz	5 GHz	200 W	11.5 dB	NA	40V	开发板	Flange
CGHV59070P	GaN on SiC	4.5 GHz	5.9 GHz	70 W	12 dB	50%	50V	封装分立晶体管	Pill
CGHV59070F-AMP	GaN on SiC	4.8 GHz	5.9 GHz	70 W	12 dB	NA	50V	开发板	Flange
CGHV59350P	GaN on SiC	5.2 GHz	5.9 GHz	350 W	11 dB	55%	50V	封装分立晶体管	Pill
CGHV59350F-AMP	GaN on SiC	5.2 GHz	5.9 GHz	350 W	11 dB	NA	50V	开发板	Flange
CGHV96050F1-AMP	GaN on SiC	7.9 GHz	8.4 GHz	50 W	>13 dB	NA	40V	开发板	Flange
CMPA0060002F-AMP	GaN on SiC	DC	6 GHz	2 W	17 dB	NA	28V	开发板	Flange
CMPA0060002F1-AMP	GaN on SiC	DC	6 GHz	2 W	18 dB	NA	28V	开发板	Flange
CMPA0060025F-AMP	GaN on SiC	DC	6 GHz	25 W	17 dB	NA	50V	开发板	Flange
CMPA0060025F1-AMP	GaN on SiC	DC	6 GHz	25 W	17 dB	NA	50V	开发板	Flange
CMPA0527005F-AMP1	GaN on SiC	1.2 GHz	1.4 GHz	5 W	20 dB	NA	50V	开发板	Flange
CMPA1D1E025F-AMP	GaN on SiC	13.5 GHz	14.5 GHz	25 W	26 dB	NA	40V	开发板	Flange
CMPA2060035F-AMP	GaN on SiC	2 GHz	6 GHz	35 W	27 dB	NA	28V	开发板	Flange
CMPA2560025F-AMP	GaN on SiC	2.5 GHz	6 GHz	25 W	24 dB	NA	28V	开发板	Flange
CMPA2735075F1-AMP	GaN on SiC	2.7 GHz	3.5 GHz	75 W	29 dB	NA	28V	开发板	Flange
CMPA2738060F-AMP	GaN on SiC	2.7 GHz	3.8 GHz	80 W	34 dB	NA	50V	开发板	Flange
CMPA5259025F-AMP	GaN on SiC	5.2 GHz	5.9 GHz	37 W	32 dB	NA	28V	开发板	Flange
CMPA5259050F-AMP	GaN on SiC	5.2 GHz	5.9 GHz	50 W	30 dB	NA	28V	开发板	Flange
CMPA5585030F-AMP	GaN on SiC	5.5 GHz	8.5 GHz	30 W	25 dB	NA	28V	开发板	Flange
CMPA601C025F-AMP	GaN on SiC	6 GHz	12 GHz	25 W	33 dB	NA	28V	开发板	Flange
CMPA801B025P	GaN on SiC	8 GHz	11 GHz	25 W	16 dB	36%	28V	Packaged MMIC	Pill
CMPA801B025F-AMP	GaN on SiC	8 GHz	11 GHz	25 W	16 dB	NA	28V	开发板	Flange
CMPA801B030F-AMP	GaN on SiC	8 GHz	11 GHz	30 W	16 dB	NA	28V	开发板	Flange
CMPA901A035F-AMP	GaN on SiC	9 GHz	10 GHz	40 W	34 dB	NA	28V	开发板	Flange
LTN/GTVA101K42EV-V1	GaN on SiC	0.96 GHz	1.4 GHz	1400 W	17 dB	68%	50V	封装分立晶体管	Bolt Down
LTN/GTVA311801FA-V1	GaN on SiC	2.7 GHz	3.1 GHz	180 W	15 dB	70%	50V	封装分立晶体管	Earless
GTVA355001EC	GaN on SiC	2.9 GHz	3.5 GHz	500 W	>11.5 dB	65%	50V	封装分立晶体管	Bolt Down
LTN/GTVA355001EC-V1	GaN on SiC	2.9 GHz	3.5 GHz	500 W	>11.5 dB	65%	50V	封装分立晶体管	Bolt Down
CGH55015P1	GaN on SiC	DC	6 GHz	15 W	>10.5 dB	25%	28V	封装分立晶体管	Pill
CGH35060P1	GaN on SiC	3.3 GHz	3.6 GHz	60 W	12 dB	25%	28V	封装分立晶体管	Pill
CGH35060P2	GaN on SiC	3.1 GHz	3.5 GHz	60 W	12 dB	60%	28V	封装分立晶体管	Pill
CGH55030P1	GaN on SiC	DC	6 GHz	30 W	10 dB	25%	28V	封装分立晶体管	Pill
GTVA107001EC-V1	GaN on SiC	0.96 GHz	1.215 GHz	700 W	20 dB	70%	50V	封装分立晶体管	Bolt Down
GTVA107001FC-V1	GaN on SiC	0.96 GHz	1.215 GHz	700 W	20 dB	70%	50V	封装分立晶体管	Earless
GTVA126001EC-V1	GaN on SiC	1.2 GHz	1.4 GHz	600 W	20 dB	63%	50V	封装分立晶体管	Bolt Down
GTVA126001FC-V1	GaN on SiC	1.2 GHz	1.4 GHz	600 W	20 dB	63%	50V	封装分立晶体管	Earless
PTVA042502EC-V1	LDMOS	0.47 GHz	0.806 GHz	250 W	19 dB	26%	50V	封装分立晶体管	Bolt Down
PTVA042502FC-V1	LDMOS	0.47 GHz	0.806 GHz	250 W	19 dB	26%	50V	封装分立晶体管	Earless
PTVA043502EC-V1	LDMOS	DC	1.35 GHz	350 W	18 dB	30%	50V	封装分立晶体管	Bolt Down
PTVA043502FC-V1	LDMOS	DC	1.35 GHz	350 W	18 dB	30%	50V	封装分立晶体管	Earless
CGH35015P	GaN on SiC	DC	6 GHz	15 W	12 dB		28V	封装分立晶体管	Pill
CGHV96130F	GaN on SiC	8.4 GHz	9.6 GHz	130 W	7.5 dB	42%	40V	封装分立晶体管	Flange
CMPA2935150S	GaN on SiC	2.9 GHz	3.5 GHz	150 W				Packaged MMIC	Plastic
CMPA0530002S	GaN on SiC	0.5 GHz	3 GHz	2 W	13 db		28V	Packaged MMIC	表面贴装
CGHV27060MP-AMP3	GaN on SiC	0.8 GHz	2.7 GHz	60 W	16.5 dB	NA	50V	开发板	Plastic
CGHV27060MP-AMP4	GaN on SiC	DC	1 GHz	60 W	16.5 dB	NA	45V	开发板	Plastic
CG2H40035F-AMP1	GaN on SiC	0.5 GHz	3 GHz	35 W	14 dB	NA	28V	开发板	Flange
CMPA901A020S	GaN on SiC	9 GHz	10 GHz	20 W	35 dB	45%	28V	Packaged MMIC	Plastic
CMPA801B030S	GaN on SiC	7.9 GHz	11 GHz	40 W	27 dB	40%	28V	Packaged MMIC	Plastic
CMPA9396025S	GaN on SiC	9 GHz	10 GHz	35 W	27 dB	45%	40V	Packaged MMIC	Plastic
CMPA3135060S	GaN on SiC	3.1 GHz	3.5 GHz	75 W	29 dB	55%	50V	Packaged MMIC	Plastic
CMPA5259050S	GaN on SiC	5.2 GHz	5.9 GHz	50 W	30 dB	50%	28V	Packaged MMIC	表面贴装
CMPA5259080S	GaN on SiC	5.2 GHz	5.9 GHz	80 W	22 dB	44%	40V	Packaged MMIC	表面贴装
CMPA5259025S	GaN on SiC	5.2 GHz	5.9 GHz	40 W	25 dB	54%	28V	Packaged MMIC	Plastic
CMPA801B030F1	GaN on SiC	8 GHz	12 GHz	35 W	19 dB	36%	28V	Packaged MMIC	Flange
CMPA1C1D080F	GaN on SiC	12.75 GHz	13.25 GHz	90 W	25 dB	21%	40V	Packaged MMIC	Flange

电话：029-88256270 传真：029-88257182 网址：www.aiboco.com 邮箱：sales@aiboco.com
