继电器继电器插座控制装置
Esterline Power Systems是世界上最大的继电器，接触器，压力开关和航空航天和飞机开关的制造商，许多专门针对恶劣环境设计。
继电器
军用合格的小型和半晶体可继电器用于商业和军事应用。 低电平至75安培 AC，DC。 适用于恶劣环境。
接触
用于主电源控制的大功率接触器。 从25安培到1000安培 包括用于现代配电系统的智能和母线安装接触器。
控制设备
为了时序目的，检测和保护电流，电压，频率和相位; 固定，可调AC和DC版本。
套接字
具有用于Leach继电器，时间延迟和轨道设备的各种插座，包括PC板安装，焊接，压接和轨道安装样式。
| Amps | Series | Description / Mil-Specification | Additional Info |
| Esterline/Leach Relays | |||
| 1A | D | RELAY LATCH, 2PDT, 1A@28VDC |  |
| 1A | E | RELAY NONLATCH, 2PDT, 1A@28VDC | |
| 10A | JS | RELAY NONLATCH, 1PDT, 10A@28VDC | |
| 10A | JSA | RELAY NONLATCH, 1PDT, 10A@28VDC | |
| 10A | YC | RELAY NONLATCH, 3PDT, 10A@28VDC M83536/21, /22 | |
| 10A | 9330 | RELAY NONLATCH, 2PDT, 10A@28VDC MS24149 | |
| 10A | JA | RELAY NONLATCH, 2PDT, 10A@28VDC M83536/11 | |
| 10A | YCA | RELAY NONLATCH, 3PDT, 10A@28VDC | |
| 10A | KA | RELAY NONLATCH, 4PDT, 10A@28VDC M83536/17 | |
| 10A | YCL | RELAY LATCH, 3PDT, 10A@28VDC M6106/40 | |
| 10A | F601 | RELAY NONLATCH, 6PDT, 10A@28VDC | |
| 10A | F600 | RELAY NONLATCH, 6PDT, 10A@28VDC | |
| 10A | XCL | RELAY LATCH, 1PDT, 10A@28VDC | |
| 10A | XC | RELAY NONLATCH, 1PDT, 10A@28VDC | |
| 12A | J | RELAY NONLATCH, 2PDT, 12A@28VDC M83536/9, /10 | |
| 12A | JL | RELAY LATCH, 2PDT, 12A@28VDC M83536/12, /13 | |
| 12A | K | RELAY NONLATCH, 4PDT, 12A@28VDC M83536/15, /16, MS27709 | |
| 12A | KL | RELAY LATCH, 4PDT, 12A@28VDC M83536/18, /19 | |
| 15A | 9274 | RELAY LATCH, 4PDT, 15A@28VDC MS24568 | |
| 2A | GP5 | RELAY NONLATCH, 2PDT, 2A@28VDC | |
| 2A | GP2/GP2A | RELAY LATCH, 2PDT, 2A@28VDC | |
| 2A | GP250 | RELAY LATCH, 2PDT, 2A@50VDC | |
| 2A | W260 | RELAY NONLATCH, 2PDT, 2A@28VDC M39016/6 | |
| 2A | WN460 | RELAY NONLATCH, 4PDT, 2A@28VDC | |
| 2A | F250 | RELAY NONLATCH, 2PDT, 2A@28VDC | |
| 25A | KCL | RELAY LATCH, 3PDT, 25A@28VDC MS27742 | |
| 25A | 9324 | RELAY NONLATCH, 3PST/NO, 25A@28VDC MS27418 | |
| 25A | 9325 | RELAY NONLATCH, 3PDT/CO, 25A@28VDC MS27706 | |
| 25A | 9339 | RELAY NONLATCH, 3PST/NO, 1PDT+AUX, 25A@28VDC M6106/41 | |
| 25A | KC | RELAY NONLATCH, 3PDT, 25A@28VDC M83536/32, /33 | |
| 25A | KCA | RELAY NONLATCH, 3PDT, 25A@28VDC-AC COIL | |
| 25A | KDL | RELAY LATCH, 3PST/NO+AUX, 25A@28VDC M6106/12 | |
| 25A | KD | RELAY NONLATCH, 3PST/NO+AUX, 25A@28VDC M6106/13 | |
| 25A | KDA | RELAY NONLATCH, 3PST/NO+AUX, 25A@28VDC M6106/13 | |
| 25A | JCL | RELAY LATCH, 1PDT, 25A@28VDC M6106/20 | |
| 25A | JC AND JCA | RELAY NONLATCH, 1PDT, 25A@28VDC M6106/19, M83536,36, /37 | |
| 5A | XA | RELAY NONLATCH, 2PDT, 5A@28VDC | |
| 5A | XL | RELAY LATCH, 2PDT, 5A@28VDC M6106/38 | |
| 5A | YA | RELAY NONLATCH, 4PDT, 5A@28VDC | |
| 5A | X | RELAY NONLATCH, 2PDT, 5A@28VDC M83536/1, /2, DSCC# 84133-XXX | |
| 5A | Y | RELAY NONLATCH, 4PDT, 5A@28VDC M83536/5, /6, DSCC# 86087-XXX | |
| 5A | YL | RELAY LATCH, 4PDT, 5A@28VDC M6106/39 | |
| 50A | KM | RELAY NONLATCH, 1PST DM, 50A@28VDC | |
| 75A | KXL | RELAY LATCH, 1PST/NO DB, 75A@28VDC | |
| 75A | KX | RELAY NONLATCH, 1PST/NO DB, 75A@28VDC | |
| Space | |||
| 1A | D | RELAY LATCH, 2PDT, 1A@28VDC | |
| 1A | E | RELAY NONLATCH, 2PDT, 1A@28VDC | |
| 2A | GP5 | RELAY NONLATCH, 2PDT, 2A@28VDC | |
| 2A | GP2/GP2A | RELAY LATCH, 2PDT, 2A@28VDC | |
| 2A | GP250 | RELAY LATCH, 2PDT, 2A@50VDC | |
| Rail | |||
| 0.5A | F257 | RELAY NONLATCH, 2PDT, 0.5A@72DC | |
| 1A | F670 | RELAY NONLATCH, 6PDT, 1A@72DC | |
| 1A | F***M06, M07 | HERMETICALLY SEALED WITH HOLDING COIL, 2PDT, 1A@72DC | |
| 1A | F472 | LATCHING HERMETICALLY SEALED, 4PDT, 1A@72DC | |
| 1A | F370 | RELAY NONLATCH, 2PDT, 1A@72DC | |
| 1A | F470 | RELAY NONLATCH, 4PDT, 1A@72DC | |
| 2A | W260 | RELAY NONLATCH, 2PDT, 2A@28VDC | |
| 3A | FD472 | LATCHING HERMETICALLY SEALED, 2NC-NO(DB-DM), 3A@72VDC | |
| 3A | FD470 | RELAY NONLATCH, 2PDT, 3A@72VDC | |
| 3A | FD670 | RELAY NONLATCH, 3PDT (DB-DM), 3A@72VDC | |
| 3A | F670S1 | RELAY NONLATCH, 1NC-NO (DB-DM) + 4PDT, 3A@72VDC | |
| 3A | FD370 | RELAY NONLATCH, 1PDT (DB-DM), 3A@72VDC | |
| 3A | F470S1 | RELAY NONLATCH, 1NC-NO (DB-DM) + 2PDT, 3A@72VDC | |
| 3A | F670S2 | RELAY NONLATCH, 2NC-NO (DB-DM) + 2PDT, 3A@72VDC | |
| 4A | 144 | RELAY NONLATCH, 2PDT. 4A@28VDC | |
| Amps | Series | Description / Mil-Specification | Additional Info |
| Esterline/Leach Contactors | |||
| 100A | 9213 | CONTACTOR NONLATCH, 3PST DM, 100A@28VDC | |
| 100A | 9207 | CONTACTOR NONLATCH, 100A@28VDC DSCC# 84192-XXX |  |
| 100A | ZC, ZCD | CONTACTOR CENTER OFF, 100A@115VAC/400HZ | |
| 100A | Z-X9YN | PLUG-IN CONTACTOR, NONLATCH, 3PDT 100A@115VAC/400HZ | |
| 120A | Z, ZD | CONTACTOR NONLATCH, 120A@115VAC/400HZ | |
| 120A | ZL, ZLD | CONTACTOR LATCH, 120A@115VAC/400HZ | |
| 125A | 129 | CONTACTOR NONLATCH, 1PST DB-DM+AUX, 125A@28VDC | |
| 145A | ZG | CONTACTOR NONLATCH, 145A@115VAC/400HZ | |
| 175A | WE-X2YN | SMART PLUG-IN CONTACTOR, NONLATCH, 175A@115VAC/400HZ | |
| 180A | ZJ | CONTACTOR NONLATCH, 180A@115VAC/400HZ | |
| 200A | 219 | CONTACTOR NONLATCH, 1PST DB+AUX, 200A@28VDC | |
| 200A | 7264-4654 | CONTACTOR NONLATCH, 1PST DM, 200A@28VDC MS24171-D1 | |
| 200A | CC02XXP | NON-LATCHING BUSBAR CONTACTOR, 1PSTNO(DB)+AUX, 200A@28VDC | |
| 25A | 9123 | CONTACTOR NONLATCH, 3PST DM, 25A@28VDC MS27997 | |
| 250A | WC | CONTACTOR CENTER OFF, 250A@15VAC/400HZ | |
| 275A | WB | CONTACTOR BUSBAR, 275A@115VAC/400HZ | |
| 275A | W | CONTACTOR LATCH, 275A@115VAC/400HZ | |
| 275A | WL | CONTACTOR LATCH, 275A@115VAC/400HZ | |
| 275A | W-X9YN | PLUG-IN CONTACTOR, NONLATCH, 275A@115VAC/400HZ | |
| 400A | AJ | CONTACTOR NONLATCH, 1PST DM, 400A@28VDC M6106/33 | |
| 400A | 7401-4658 | CONTACTOR NONLATCH, 1PST DM, 400A@28VDC MS24185-D1 | |
| 400A | CC04XXP | NON-LATCHING BUSBAR CONTACTOR, 1PSTNO(DM)+AUX, 400A@28VDC | |
| 50A | 9125 | CONTACTOR NONLATCH INTERLOCK, (3PST DM CO)X2, | |
| 50A | HB | CONTACTOR BUSBAR, 50A@115VAC/400HZ | |
| 50A | HC,HCD,HCP | CONTACTOR CENTER OFF, 50A@115VAC/400HZ MS27750 | |
| 50A | 9124 | CONTACTOR NONLATCH, 3PST DM, 50A@28VDC MS27222 | |
| 50A | 7064-4653 | CONTACTOR NONLATCH, 1PST DM, 50A@28VDC MS24166-D1 | |
| 500A | 507 | CONTACTOR NONLATCH, 1PST DM, 500A@28VDC | |
| 50A | 7064-4656 | CONTACTOR NONLATCH, 1PST DM, 50A@28VDC MS24166-D1 | |
| 60A | H,HD,HP, HT,HDT,HPT | CONTACTOR NONLATCH, 60A@115VAC/400HZ MS27751, M6106/26, M6106/43 | |
| 60A | HL,HLT, HLD,HLP | CONTACTOR LATCH, 60A@115VAC/400HZ MS27749 | |
| 60A | ZE-X9YN | SMART PLUG-IN CONTACTOR, NONLATCH, 3PST 60A@115VAC/400HZ | |
| 700A | M 707 | CONTACTOR NONLATCH, 1PST DM, 700A@28VDC | |
| 80A | 77 | CONTACTOR NONLATCH, 1PST DM, 80A@28VDC | |
| 90A | L | CONTACTOR NONLATCH, 90A@115VAC/400HZ | |
| 90A | LC | CONTACTOR CENTER OFF, 90A@115VAC/400HZ | |
| Series | Description / Mil-Specification | Additional Info |
| Esterline/Leach Control Devices | ||
| TDH-1609 | TIME DELAY ON OPERATE FIXED, 1PNO(SSO), 0.15A@28VDC M83726/24 |  |
| TDH-1610 | TIME DELAY ON RELEASE FIXED, 1PNO(SSO), 0.15A@28VDC M83726/25 | |
| FLSH402 | TIME DELAY PROGRAMMABLE TIME/FUNCTION, 2PST(SSO), 0.25A@28VDC | |
| F410 | SENSOR, FREQUENCY, 2PDT OR 4PDT, 10A@28VDC | |
| TDH-7050/7051 | TIME DELAY ON OPERATE FIXED, 4PDT, 10A@28VDC | |
| TDH-7060/7061 | TIME DELAY ON OPERATE ADJI 4PDT, 10A@28VDC | |
| TDH-6050/6051 | TIME DELAY ON OPERATE FIXED, 2PDT, 10A@28VDC | |
| TDH-7070/7071 | TIME DELAY ON RELEASE FIXED, 4PDT, 10A@28VDC | |
| TDH-6060/6061 | TIME DELAY ON OPERATE ADJ, 2PDT, 10A@28VDC | |
| V610 | SENSOR, AC POWER MONITOR, 2PDT OR 4PDT, 10A@28VDC | |
| TDH-8050/8051 | TIME DELAY ON OPERATE FIXED, 2PDT, 10A@28VDC M83726/28 | |
| TDH-6070/6071 | TIME DELAY ON RELEASE FIXED, 2PDT, 10A@28VDC | |
| TDH-8060/8061 | TIME DELAY ON OPERATE ADJ, 2PDT, 10A@28VDC M83726/30 | |
| TDH-8070/8071 | TIME DELAY ON RELEASE FIXED, 2PDT, 10A@28VDC M83726/29 | |
| TDH-8080/8081 | TIME DELAY ON RELEASE ADJ, 2PDT, 10A@28VDC M83726/31 | |
| P510 | SENSOR, AC PHASE SEQUENCE, 2PDT OR 4PDT, 10A@28VDC | |
| V110 | SENSOR, DC VOLTAGE, 2PDT OR 4PDT, 10A@28VDC | |
| V210 | SENSOR, AC UNDER VOLTAGE, 2PDT OR 4PDT, 10A@28VDC | |
| V310 | SENSOR, AC OVERVOLTAGE, 2PDT OR 4PDT, 10A@28VDC | |
| VS400 | SENSOR, UNDERVOLTAGE, 2PDT, 2A@28VDC | |
| CS400 | SENSOR, CURRENT, 2PDT, 2A@28VDC | |
| CS500 | SENSOR, CURRENT, 2PDT, 2A@28VDC | |
| T531 | TIME DELAY ON OPERATE/RELEASE, FIXED/ADJ, 3PDT, 25A@28VDC | |
| TD-1435 | TIME DELAY ON OPERATE FIXED, 1PST, 0.25A@28VDC M83726/20 | |
| TD-1436 | TIME DELAY ON OPERATE ADJ, 1PST, 0.25A@28VDC M83726/21 | |
| CSHM | SENSOR, HALL EFFECT FOR CURRENT MEASUREMENT | |
| CSHP-01 | SENSOR, HALL EFFECT FOR RCCB OPERATION | |
| CSHPB | SENSOR, HALL EFFECT FOR BATTERY BUS DIRECT AND RETURN PROTECTION | |
| TD-1412 | TIME DELAY REPEAT CYCLE TIMER, 1PST, 0.25A@28VDC M83726/22 | |
| Rail | ||
| THLAO | TIME DELAY ON OPERATE PROGRAMMABLE TIME, 1PSTNO (SSO), 0.25A | |
| THLC | TIME DELAY ON REPEAT CYCLE PROGRAMMABLE TIMER, 1PSTNO (SSO), 0.25A | |
| THLM | TIME DELAY ON RELEASE WITHOUT CONTROL PROGRAMMABLE TIMER, 1PSTNO (SSO), 0.25A | |
| THLOR | TIME DELAY ON RELEASE WITH CONTROL PROGRAMMABLE TIMER, 1PSTNO (SSO), 0.25A | |
| Series | Description | Additional Info |
| Esterline/Leach Relay Sockets | ||
| SO-1049-8772/8774 | SOCKET TO CRIMP FOR JA | |
| SO-1021-7127/7126 | SOCKET TO SOLDER FOR V110, V210, V310, V710, F410 AND P510 | |
| SO-1064-10425 | SOCKET TO CRIMP FOR XC | |
| SO-1065-001 | SOCKET TO CRIMP FOR YC | |
| SO-1065-003 | SOCKET TO CRIMP FOR YCL | |
| SO-1065-10392/10393 | SOCKET TO CRIMP FOR YCA | |
| S600, S601 | SOCKET TO CRIMP FOR F600 AND F601 | |
| SO-1056-8691 | SOCKET TO CRIMP FOR KL, TDH-7050, TDH-7060, AND TDH-7070 | |
| SO-1048-8776/8779 | SOCKET TO CRIMP FOR KA AND CS400 | |
| SO-1048-8308/8518 | SOCKET TO CRIMP FOR K, TDH-8050, TDH-8060, TDH-8070, TDH-8080 AND VS400 | |
| SO-1049-8309/8987 | SOCKET TO CRIMP FOR J | |
| SO-1055-8690-10147 | SOCKET TO CRIMP FOR JL, TDH-6050, TDH-6060 AND TDH-6070 | |
| HRCW | SOCKET TO SOLDER FOR F250, F257, W260, WB260, 144 | |
| HRCC | SOCKET TO SOLDER FOR WN460 | |
| SO-1060-8915 | SOCKET TO CRIMP FOR KDL | |
| SO-1063-9033/9034 | SOCKET TO CRIMP FOR JS/JSA AND JC/JCA | |
| SO-1057-8912 | SOCKET TO CRIMP FOR KC | |
| SO-1063-9036 | SOCKET TO CRIMP FOR JCL | |
| SO-1059-8914 | SOCKET TO CRIMP FOR KD | |
| SO-1058-8913 | SOCKET TO CRIMP FOR KCL | |
| SO-1061-8916 | SOCKET TO CRIMP FOR KDA | |
| SO-1062-8917 | SOCKET TO CRIMP FOR KCA | |
| SO-1064-10444/10445 | SOCKET TO CRIMP FOR XA | |
| SO-1064-003 | SOCKET TO CRIMP FOR XL | |
| SO-1064-001 | SOCKET TO CRIMP FOR X | |
| SO-1066-10385/10386 | SOCKET TO CRIMP FOR YA | |
| SO-1066-001 | SOCKET TO CRIMP FOR Y | |
| SO-1066-003 | SOCKET TO CRIMP FOR YL | |
| MT-3000-003 | RELAY SOCKET TRACK FOR ALL SM SERIES SOCKETS | |
| SM-1001-003 | SOCKET TRACK MOUNT FOR YC | |
| SM-1002-003 | SOCKET TRACK MOUNT FOR Y | |
| SM-1000-003 | SOCKET TRACK MOUNT FOR X, TDH-1609 AND TDH-1610 | |
| RAIL | ||
| SFE*7* | SOCKET PCB FOR F370,F470,F570,F670 AND TIMERS | 1A@72DC, 2 TO 6PDT |
| HRCW | SOCKET TO SOLDER FOR F250, F257, W260, WB260 AND 144 | 2A@28VDC, 2PDT |
| SF400-1F | SOCKET WITH TAB FOR F470, F470S1 AND FD470 (OPTION H) | 3A@72VDC, 4PDT |
| SF402-1F | SOCKET TAB FOR F472, FD472, THLOR, THLM, THLC AND THLAO | 3A@72VDC, 4PDT |
| SF600-2F | SOCKET TAB FOR F670, FD670 (OPTION H), F670S1 AND F670S2 | 3A@72VDC, 6PDT |
| SF*CE40E-* | SOCKET PCB FOR F300, FD300, F370, FD370, F470, F470S1, FD470, F472, FD472, F472, THLOR, THLM, THLC, THLAO, FD600, FD670, FD400 | 3A@72VDC, 2 TO 6PDT |
| 081E03-00 | LABEL HOLDER, RAILWAY ACCESSORY | |
| 081E04-00 | FRAME ADAPTER, RAILWAY ACCESSORY | |
| EC400 | COIL SUPPRESSION MODULE, RAILWAY ACCESSORY | |
