订货代码 | 线规 (AWG) | 绞合导体 | 芯线 | 护套直径 inches (mm) | 屏蔽直径 inches (mm) | 屏蔽 |
M27500-10WP1N24 | 10 | 37/26 | 1 | .146 (3.70) | .137 (3.48) | 镀镍铜编织 85%覆盖率 |
M27500-10WP1S24 | 10 | 37/26 | 1 | .146 (3.70) | .137 (3.48) | 镀银铜编织 85%覆盖率 |
M27500-10WP2N24 | 10 | 37/26 | 2 | .271 (6.87) | .262 (6.65) | 镀镍铜编织 85%覆盖率 |
M27500-10WP2S24 | 10 | 37/26 | 2 | .271 (6.87) | .262 (6.65) | 镀银铜编织 85%覆盖率 |
M27500-10WP3N24 | 10 | 37/26 | 3 | .289 (7.34) | .280 (7.12) | 镀镍铜编织 85%覆盖率 |
M27500-10WP3S24 | 10 | 37/26 | 3 | .289 (7.34) | .280 (7.12) | 镀银铜编织 85%覆盖率 |
M27500-10WP4N24 | 10 | 37/26 | 4 | .324 (8.23) | .312 (7.9) | 镀镍铜编织 85%覆盖率 |
M27500-10WP4S24 | 10 | 37/26 | 4 | .324 (8.23) | .312 (7.9) | 镀银铜编织 85%覆盖率 |
M27500-12WP1N24 | 12 | 37/28 | 1 | .123 (3.12) | .114 (2.90) | 镀镍铜编织 85%覆盖率 |
M27500-12WP1S24 | 12 | 37/28 | 1 | .123 (3.12) | .114 (2.90) | 镀银铜编织 85%覆盖率 |
M27500-12WP2N24 | 12 | 37/28 | 2 | .221 (5.60) | .212 (5.38) | 镀镍铜编织 85%覆盖率 |
M27500-12WP2S24 | 12 | 37/28 | 2 | .221 (5.60) | .212 (5.38) | 镀银铜编织 85%覆盖率 |
M27500-12WP3N24 | 12 | 37/28 | 3 | .235 (5.98) | .227 (5.76) | 镀镍铜编织 85%覆盖率 |
M27500-12WP3S24 | 12 | 37/28 | 3 | .235 (5.98) | .227 (5.76) | 镀银铜编织 85%覆盖率 |
M27500-12WP4N24 | 12 | 37/28 | 4 | .265 (6.73) | .256 (6.5) | 镀镍铜编织 85%覆盖率 |
M27500-12WP4S24 | 12 | 37/28 | 4 | .265 (6.73) | .256 (6.5) | 镀银铜编织 85%覆盖率 |
M27500-14WP1N24 | 14 | 19/27 | 1 | .103 (2.61) | .094 (2.39) | 镀镍铜编织 85%覆盖率 |
M27500-14WP1S24 | 14 | 19/27 | 1 | .103 (2.61) | .094 (2.39) | 镀银铜编织 85%覆盖率 |
M27500-14WP2N24 | 14 | 19/27 | 2 | .181 (4.59) | .172 (4.37) | 镀镍铜编织 85%覆盖率 |
M27500-14WP2S24 | 14 | 19/27 | 2 | .181 (4.59) | .172 (4.37) | 镀银铜编织 85%覆盖率 |
M27500-14WP3N24 | 14 | 19/27 | 3 | .192 (4.89) | .184 (4.67) | 镀镍铜编织 85%覆盖率 |
M27500-14WP3S24 | 14 | 19/27 | 3 | .192 (4.89) | .184 (4.67) | 镀银铜编织 85%覆盖率 |
M27500-14WP4N24 | 14 | 19/27 | 4 | .213 (5.40) | .204 (5.2) | 镀镍铜编织 85%覆盖率 |
M27500-14WP4S24 | 14 | 19/27 | 4 | .213 (5.40) | .204 (5.2) | 镀银铜编织 85%覆盖率 |
M27500-16WP1N24 | 16 | 19/29 | 1 | .090 (2.28) | .081 (2.06) | 镀镍铜编织 85%覆盖率 |
M27500-16WP1S24 | 16 | 19/29 | 1 | .090 (2.28) | .081 (2.06) | 镀银铜编织 85%覆盖率 |
M27500-16WP2N24 | 16 | 19/29 | 2 | .155 (3.93) | .146 (3.71) | 镀镍铜编织 85%覆盖率 |
M27500-16WP2S24 | 16 | 19/29 | 2 | .155 (3.93) | .146 (3.71) | 镀银铜编织 85%覆盖率 |
M27500-16WP3N24 | 16 | 19/29 | 3 | .164 (4.18) | .156 (3.96) | 镀镍铜编织 85%覆盖率 |
M27500-16WP3S24 | 16 | 19/29 | 3 | .164 (4.18) | .156 (3.96) | 镀银铜编织 85%覆盖率 |
M27500-16WP4N24 | 16 | 19/29 | 4 | .181 (4.60) | .173 (4.4) | 镀镍铜编织 85%覆盖率 |
M27500-16WP4S24 | 16 | 19/29 | 4 | .181 (4.60) | .173 (4.4) | 镀银铜编织 85%覆盖率 |
M27500-18WP1N24 | 18 | 19/30 | 1 | .083 (2.10) | .074 (1.88) | 镀镍铜编织 85%覆盖率 |
M27500-18WP1S24 | 18 | 19/30 | 1 | .083 (2.10) | .074 (1.88) | 镀银铜编织 85%覆盖率 |
M27500-18WP2N24 | 18 | 19/30 | 2 | .141 (3.57) | .132 (3.35) | 镀镍铜编织 85%覆盖率 |
M27500-18WP2S24 | 18 | 19/30 | 2 | .141 (3.57) | .132 (3.35) | 镀银铜编织 85%覆盖率 |
M27500-18WP3N24 | 18 | 19/30 | 3 | .149 (3.79) | .141 (3.57) | 镀镍铜编织 85%覆盖率 |
M27500-18WP3S24 | 18 | 19/30 | 3 | .149 (3.79) | .141 (3.57) | 镀银铜编织 85%覆盖率 |
M27500-18WP4N24 | 18 | 19/30 | 4 | .164 (4.18) | .156 (4.0) | 镀镍铜编织 85%覆盖率 |
M27500-18WP4S24 | 18 | 19/30 | 4 | .164 (4.18) | .156 (4.0) | 镀银铜编织 85%覆盖率 |
M27500-20WP1N24 | 20 | 19/32 | 1 | .075 (1.90) | .066 (1.68) | 镀镍铜编织 85%覆盖率 |
M27500-20WP1S24 | 20 | 19/32 | 1 | .075 (1.90) | .066 (1.68) | 镀银铜编织 85%覆盖率 |
M27500-20WP2N24 | 20 | 19/32 | 2 | .125 (3.17) | .116 (2.95) | 镀镍铜编织 85%覆盖率 |
M27500-20WP2S24 | 20 | 19/32 | 2 | .125 (3.17) | .116 (2.95) | 镀银铜编织 85%覆盖率 |
M27500-20WP3N24 | 20 | 19/32 | 3 | .132 (3.36) | .124 (3.14) | 镀镍铜编织 85%覆盖率 |
M27500-20WP3S24 | 20 | 19/32 | 3 | .132 (3.36) | .124 (3.14) | 镀银铜编织 85%覆盖率 |
M27500-20WP4N24 | 20 | 19/32 | 4 | .145 (3.69) | .137 (3.5) | 镀镍铜编织 85%覆盖率 |
M27500-20WP4S24 | 20 | 19/32 | 4 | .145 (3.69) | .137 (3.5) | 镀银铜编织 85%覆盖率 |
M27500-22WP1N24 | 22 | 19/34 | 1 | .067 (1.69) | .058 (1.47) | 镀镍铜编织 85%覆盖率 |
M27500-22WP1S24 | 22 | 19/34 | 1 | .067 (1.69) | .058 (1.47) | 镀银铜编织 85%覆盖率 |
M27500-22WP2N24 | 22 | 19/34 | 2 | .109 (2.76) | .100 (2.54) | 镀镍铜编织 85%覆盖率 |
M27500-22WP2S24 | 22 | 19/34 | 2 | .109 (2.76) | .100 (2.54) | 镀银铜编织 85%覆盖率 |
M27500-22WP3N24 | 22 | 19/34 | 3 | .115 (2.92) | .106 (2.70) | 镀镍铜编织 85%覆盖率 |
M27500-22WP3S24 | 22 | 19/34 | 3 | .115 (2.92) | .106 (2.70) | 镀银铜编织 85%覆盖率 |
M27500-22WP4N24 | 22 | 19/34 | 4 | .126 (3.20) | .117 (3.0) | 镀镍铜编织 85%覆盖率 |
M27500-22WP4S24 | 22 | 19/34 | 4 | .126 (3.20) | .117 (3.0) | 镀银铜编织 85%覆盖率 |
M27500-24WP1N24 | 24 | 19/36 | 1 | .061 (1.54) | .052 (1.32) | 镀镍铜编织 85%覆盖率 |
M27500-24WP1S24 | 24 | 19/36 | 1 | .061 (1.54) | .052 (1.32) | 镀银铜编织 85%覆盖率 |
M27500-24WP2N24 | 24 | 19/36 | 2 | .097 (2.45) | .088 (2.24) | 镀镍铜编织 85%覆盖率 |
M27500-24WP2S24 | 24 | 19/36 | 2 | .097 (2.45) | .088 (2.24) | 镀银铜编织 85%覆盖率 |
M27500-24WP3N24 | 24 | 19/36 | 3 | .102 (2.59) | .093 (2.37) | 镀镍铜编织 85%覆盖率 |
M27500-24WP3S24 | 24 | 19/36 | 3 | .102 (2.59) | .093 (2.37) | 镀银铜编织 85%覆盖率 |
M27500-24WP4N24 | 24 | 19/36 | 4 | .111 (2.83) | .103 (2.6) | 镀镍铜编织 85%覆盖率 |
M27500-24WP4S24 | 24 | 19/36 | 4 | .111 (2.83) | .103 (2.6) | 镀银铜编织 85%覆盖率 |
M27500-26WP1N24 | 26 | 19/38 | 1 | .057 (1.44) | .048 (1.22) | 镀镍铜编织 85%覆盖率 |
M27500-26WP1S24 | 26 | 19/38 | 1 | .057 (1.44) | .048 (1.22) | 镀银铜编织 85%覆盖率 |
M27500-26WP2N24 | 26 | 19/38 | 2 | .089 (2.25) | .080 (2.03) | 镀镍铜编织 85%覆盖率 |
M27500-26WP2S24 | 26 | 19/38 | 2 | .089 (2.25) | .080 (2.03) | 镀银铜编织 85%覆盖率 |
M27500-26WP3N24 | 26 | 19/38 | 3 | .093 (2.37) | .085 (2.15) | 镀镍铜编织 85%覆盖率 |
M27500-26WP3S24 | 26 | 19/38 | 3 | .093 (2.37) | .085 (2.15) | 镀银铜编织 85%覆盖率 |
M27500-26WP4N24 | 26 | 19/38 | 4 | .102 (2.58) | .093 (2.4) | 镀镍铜编织 85%覆盖率 |
M27500-26WP4S24 | 26 | 19/38 | 4 | .102 (2.58) | .093 (2.4) | 镀银铜编织 85%覆盖率 |
