主称代码 | ABS1356 |
执行标准 | EN3475,ABS1356 |
芯线 | ABS0949AD |
导体材料 | AWG24至4:镀镍铜包铝,其他:镀镍铝 |
绝缘材料 | 聚酰亚胺 |
屏蔽材料 | 镀镍铜 |
护套材料 | 聚酰亚胺,PTFE,激光打标 |
温度范围 | -60至+180℃ |
额定电压 | 600伏 |
线规范围 | 24至000 |
工作频率 | 0.002MHz |
电弧电痕 | 是 |
RoHS性能 | 是 |
耐飞机流体 | 非常好 |
阻燃性能 | FAR 25.869 |
| 订货代码 | 导线截面 | 线规 | 绞合导体 | 外径 | 电缆外径 | 直流电阻 | 重量 | |
| mm² | AWG | nb x mm | mm | Min. | Max. | Ω/km | kg/km | |
| NSA935131DG10 | 5.15 | 10 | 73x0.30 | 3.3 | 4.1 | 4.5 | 3.9 | 64.5 |
| NSA935131DG8 | 8.98 | 8 | 127x0.30 | 4.5 | 5.2 | 5.6 | 2.3 | 108 |
| NSA935131DG6 | 13.4 | 6 | 27x7x0.30 | 5.6 | 6.3 | 7.3 | 1.6 | 160 |
| NSA935131DG4 | 21.8 | 4 | 37x12x0.25 | 7.3 | 8.1 | 9.3 | 0.97 | 245 |
| NSA935131DG2 | 34.5 | 2 | 37x19x0.25 | 8.8 | 9.7 | 10.9 | 0.61 | 396 |
| NSA935131DG1 | 41.8 | 1 | 37x23x0.25 | 10 | 10.6 | 12.1 | 0.5 | 470 |
| NSA935131DG0 | 52.7 | 0 | 37x29x0.25 | 11.3 | 11.8 | 13.4 | 0.4 | 600 |
| NSA935131DG00 | 67.2 | 0 | 37x37x0.25 | 12.5 | 13.6 | 14.5 | 0.31 | 750 |
| NSA935131DG000 | 84.8 | 0 | 48x36x0.25 | 14.4 | 15.6 | 16.8 | 0.25 | 950 |
| NSA935131DG0000 | 107.8 | 0 | 61x36x0.25 | 15.9 | 17 | 18.4 | 0.2 | 1200 |
