MIL-W-22759/42 Wire (M22759/42 Wire) Construction:

Conductor: Nickel coated high strength copper alloy

Insulation: XL-ETFE

Jacket: XL-ETFE

MIL-W-22759/42 Wire (M22759/42 Wire) Ratings:

Voltage Rating: 600 Volts

Temperature Rating: 200°C

PART NUMBER    AWG    Conductor Stranding    Approx LBS/MFT    min O.D. (in)    Max O.D. (in)    Cond. Material    Max. Temp    Voltage

M22759/42-26-0    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-1    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-2    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-3    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-4    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-5    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-6    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-7    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-8    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-26-9    26    19/38    1.7    0.038    0.042    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-0    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-1    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-2    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-3    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-4    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-5    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-6    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-7    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-8    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

M22759/42-24-9    24    19/36    2.3    0.043    0.047    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-0    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-1    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-2    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-3    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-4    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-5    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-6    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-7    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-8    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-22-9    22    19/34    3.3    0.048    0.052    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-0    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-1    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-2    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-3    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-4    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-5    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-6    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-7    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-8    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600

m22759/42-20-9    20    19/32    4.8    0.056    0.06    Nickel coated high strength copper alloy    200°C    600
