应用：航空航天应用，中等重量，耐磨性和机械耐久性是必需的

特性：高镍高强度铜合金导线

膨化聚四氟乙烯（PTFE）绝缘，按照mil-std-681颜色编码

温度：260°

额定电压：1000伏

MIL-W-22759/22 (M22759/22) | SAE AS22759/22

 Finished Wire

Mil-Spec #            AWG    Stranding  Min O.D. (in)  Max O.D. (in)    />

M22759/21-28-*    28       7/36           0.041          0.045             1.93

M22759/21-26-*    26      19/38          0.046          0.050              2.60

M22759/21-24-*    24      19/36          0.051          0.055              3.38

M22759/21-22-*    22      19/34          0.058          0.062              4.61

M22759/21-20-*    20      19/32          0.066          0.070              6.43

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.

0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White

Example: Size 20, white - M22759/21-20-9; white with orange stripe -

M22759/21-20-93.
