mil-w-22759|SAEas22759/15
mil-w-22759/15线（m22759/15线）
sae-as22729/15
军用规格导线
m22759/15线缆构成：
导体：镀银高强度铜合金
绝缘：挤出FEP
护套：清晰的PVDF
m22759/15线额定值：
电压：600伏
温度：135°C
PART NUMBER AWG Conductor Stranding Approx LBS/MFT min O.D. (in) Max O.D. (in) Cond. Material Max. Temp Voltage
m22759/14-26-0 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-1 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-2 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-3 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-4 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-5 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-6 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-7 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-8 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-26-9 26 19/38 1.75 0.035 0.039 Silver coated high strength copper alloy 135°C 600
m22759/14-24-0 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-1 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-2 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-3 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-4 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-5 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-6 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-7 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-8 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-24-9 24 19/36 2.42 0.04 0.044 Silver coated high strength copper alloy 135°C 600
m22759/14-22-0 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-1 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-2 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-3 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-4 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-5 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-6 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-7 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-8 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-22-9 22 19/34 3.59 0.045 0.051 Silver coated high strength copper alloy 135°C 600
m22759/14-20-0 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-1 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-2 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-3 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-4 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-5 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-6 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-7 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-8 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
m22759/14-20-9 20 19/32 5.22 0.053 0.059 Silver coated high strength copper alloy 135°C 600
